Cattle Slaughtering Line

Cattle Slaughtering Line thumbnail-1
Cattle Slaughtering Line thumbnail-2
Cattle Slaughtering Line thumbnail-3
Cattle Slaughtering Line thumbnail-4
Cattle Slaughtering Line thumbnail-5
Cattle Slaughtering Line thumbnail-6
Cattle Slaughtering Line photo-1
Cattle Slaughtering Line photo-2
Cattle Slaughtering Line photo-3
Cattle Slaughtering Line photo-4
Cattle Slaughtering Line photo-5
Cattle Slaughtering Line photo-6
US$ 115,500 - 465,700 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Cattle
Place of Origin:
Shandong, China
Contact Supplier Request Quote Chat Now
Shanghai One-Stop Engineering Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application Cattle
Place of Origin Shandong, China
Brand Name ONESTOP
Model Number N/M
Voltage 380V/220V
Power(W) 140kw
Dimension(L*W*H) 56*16*12m
Weight 1500kg
Certification ISO9001:2000
After-sales Service Provided Engineers available to service machinery overseas



Cow and Bull Slaughter Line Design Halal Cattle Slaughter Line Machine Beef Production Line



       What's your Company Provide?



1

The cattle,sheep/goat,pig and poultry abattoir (slaughter)/slaughtering facilities (Include steel building facilities, refrigeration facilities, boiler, generator and so on);

2

The livestock abattoir (slaughter)/slaughter rendering plant facilities;

3

The livestock farming facilities;

4

The sausage, ham, meat ball, hamburger, hot dog processing facilities;

5

The abattoir (slaughter) waste water (sewage) treatment facilities.



       What's your Company Photo?

 cattle slaughtering linecattle slaughtering line



       What's your Machine Advantage?



1

        Authoritative certification Sluaghterhouse Equipment;

2

        Advanced design and technology;

3

        High quality guarantee;

4

        Long service life;

5

        Labor and energy saving;

6

        Easy operation and maintenance;

7

        High automatic degree;

8

        One-stop service;

9

       Experienced Slaughterhouse designer one by one service.



 -----------------------------------------------------------------------------------------------------------------------

100/day Cattles per day Slaughtering & Processing Equipment Inventory & Quotation













No.

Items

Model

Unit

Qty

Remarks

Cattle Slaughter Part

1

Leading Machine

QNJ-8

set

1

Hot galvanized steel; Length: 7.5m

2

Pneumatic Slaughter Box(with head fixing device)

FBC-2500

set

1

Hot galvanized structure; Cylinders, pneumatic components are aluminum

3

Safty Fence



set

5

Hot galvanized steel

4

Gross Cattle Hanging Lift

2T

set

1

Lifting and hanging the live cattle in standard speed

5

Automatic Hanging Device



set

1

Safe and reliable

6

Manual Bleeding Conveying Line

GST-600

meter

15

Including rail beams, hangers, track, and connections between, all made of hot galvanized

7

Bleeding Shackle



L

10

Hot galvanized steel

8

Fixed Work Platform

ZT-2

set

1

Hot galvanized table rack; Platform Size: 4500 * 1500mm. Table can be fixed hand disinfection device

9

Rehanging Lift

1T

set

1

Standard speed hanging up

10

Trolley Hook for Tubular Rail

GLG-400

set

100

Hanging frame is made of high-strength Al-alloy to reduce the weight; Hook and trolley are made of stainless steel

11

Carcass Processing Conveyor

BS-2400

set

1

It is Steping type with hot galvanized frame, chain; Tubular Rail is hot galvanized; controlled automatically or manually; including process control systems; 2400mm gap each

12

Double-polar Pneumatic Lifting Work Platform

QSST-1600

set

2

Used for pre-dehiding, halving and   trimming; hot galvanized steel frame, stainless steel cover, surface and handrail, air cylinder and pneumatic elements are Al-alloy; Platform size: 1900*1000mm, made of acid-resistant material, hand washing and disinfection device can be fixed on it, ; Lift height: 400mm~2000mm

13

Hydraulic Dehiding Machine

CPJ-50

set

1

Hot galvanized steel frame and cover, SUS peeling roller; Hydraulic system, control system and hydraulic oil included

14

Leg Fixture Device

STJ-00

set

1

Hot galvanized steel, but SUS peeling chain

15

Single-polar Pneumatic Lifting Work Platform

DT-1600

set

2

Used with dehiding machine, hot galvanized steel frame, stainless steel cover, surface and handrail, air cylinder and pneumatic elements are Al-alloy; Platform surface is made of anti-slip plate; SUS: 304

16

Work Platform for White Viscera

BZT-02

set

1

Stainless steel; Platform size: 2000*900mm, Platform surface is made of anti-slip plate, hand washing and disinfection device can be fixed on it

17

Pneumatic Chute for White Viscera

BZC-02

set

1

Stainless steel; Reception chute:1200mm wide, leading chute: 750mm wide

18

Work Platform for Red Viscera

HZT-02

set

1

Stainless steel; Platform size: 2000*1300mm, Platform surface is made of antislip plate, handwashing and disinfection device can be fixed on it

19

Chute for offals

NC-2

set

2

Hot galvanized steel frame, Stainless steel chute surface

20

On-rail scale

400Kg

set

1

Used to weigh the halved carcass, with display scree and printer

21

Manual High pressure washing gun



pc

1

Stainless steel

22

Synchronous Quarantine System(16 trays)

TWJ-16

set

1

Including hot galvanized steel drive, tension,   auto-dumping device, slide frame, rail, 16Mn detachable chain and connections; SUS big and small trays, gap 1200mm

23

Tubular Rail

DG60*4

meter

35

Hot galvanized steel

24

90' degree bend for Tube Rail

R300*90.

pc

3

Hot galvanized steel

25

Tube Rail switch

1RG,2RG,1LG,2LG

set

2

Hot galvanized steel, includes food-grade stay cord, joints and connections

26

Tube Rail hanging bracket

H225

pc

59

Hot galvanized steel, includes connections













Cattle Carcass Acid Discharge Part

1

Tube Rail

DG60*4

meter

85

Hot galvanized steel

2

90' degree bend for Tube Rail

R300*90Degree

pc

8

Hot galvanized steel

3

Tube Rail switch

1RG,2RG,1LG,2LG

set

16

Hot galvanized steel, includes food-grade stay cord, joints and connections

4

Tube Rail hanging bracket

H225

pc

124

Hot galvanized steel, includes connections

5

Tube Rail Breaker

DGQ-1

set

4

Hot galvanized steel













Cattle Deboning & Cutting Part

1

Tube Rail

DG60*4

meter

65

Hot galvanized steel

2

90' Bend for Tube Rail

R300*90Degree

pc

3

Hot galvanized steel

3

Tube Rail switch

1RG,2RG,1LG,2LG

set

4

Hot galvanized steel, includes food-grade stay cord, joints and connections

4

Tube Rail hanging bracket

H225

pc

109

Hot galvanized steel, includes connections

5

Ramp type Descending machine for quartered carcass

PTJ-1

set

1

Hot galvanized steel

6

Lifter for quartered carcass

0.5T

set

1

Normal lifting speed

7

Cutting worktable

1200*700*800

set

12

Stainless steel frame, table surface is made from antislip plastic plate

8

Packing Worktable

1800*900*800

set

6

All stainless steel



 cattle slaughtering linecattle slaughtering linecattle slaughtering linecattle slaughtering linecattle slaughtering line
