Good moldability fiberglass tape
Description:
Good moldability fiberglass tape is made of glass fiber yarns, of which the alkali metal is less than 0.8%. Good moldability fiberglass tape is weaved by non-alkali fiberglass yarn.
Good moldability fiberglass tape has good thermal resistant and insulation features. Good moldability fiberglass tape is widely used for windings of motor and transformer
Application:
Good moldability fiberglass tape is widely used for electric motors,coil of transformers as insulating binding materials.
Characteristics
Good moldability fiberglass tape has good thermal resistance
Good moldability fiberglass tape has good excellent insulating
Good moldability fiberglass tape has good corrosion resistance
Good corrosion resistance Types
| Type | Impregnating Compound | Application Domain | Application |
| The general | Olefin or silicane | Dry type transformer, arrester, Generator, cable, electric appliance and glass fiber reinforces plastic |
Filler or banding material |
| The reinforcing (bulked yard) |
Olefin or silicane | Architecture or electric | Fireproofing; High temperature resistant Airproof material |
Specification and Property
| Code | Thickness(mm) | Width(mm) | Breakdown Strength≥n/10mm | Texture | Roll Length(m) | Comment |
| ET-60 | 0.06±0.005 | 10-30 | 100 | Tabby | 200 | The general |
| ET-80 | 0.08±0.01 | 10-30 | 150 | Tabby | 200 | |
| ET-100 | 0.10±0.01 | 10-80 | 200 | Tabby/ Cheveron | 50 | |
| ET-130 | 0.13±0.015 | 10-255 | 250 | Tabby/ Cheveron | 50-200 | |
| ET-150 | 0.15±0.015 | 10-255 | 250 | Tabby/ Cheveron | 50-200 | |
| ET-160 | 0.16±0.02 | 10-255 | 300 | Tabby/ Cheveron | 50-200 | |
| ET-200 | 0.20±0.02 | 10-255 | 350 | Tabby/ Cheveron | 50-200 | |
| ET-250 | 0.25±0.025 | 10-255 | 350 | Tabby/ Cheveron | 50-200 | |
| ET-300 | 0.30±0.03 | 10-255 | 400 | Tabby/ Cheveron | 50-200 | |
| ET-1500 | 1.5±0.15 | 10-155 | Temperature Tolerance is 800 ℃ |
Tabby/ Cheveron | 30 | |
| ET-2000 | 2.0±0.20 | 10-155 | Tabby | 30 | The reinforcing | |
| ET-2500 | 2.5±0.25 | 10-155 | Tabby | 30 | ||
| ET-3000 | 3.0±0.30 | 10-155 | Tabby | 30 | ||
| Bulked yarn | Diameter:5,6,7,10(mm) | Knit | 50/100 |
|||
