Specifications
1. We are engaged in insulating material has been 20 years2.There are about 300 transformer manufacturers use our products
Electrical insulation epoxy resin wire mesh glass
Epoxy resin wire mesh glass is braided into reticulation structure by fiberglass yarn. and then coated with epoxy resin and baked. Epoxy resin wire mesh glass is used as reinforce orientation on epoxy fiberglass mesh insulation material cast resin electric appliance.
Characteristics
Good performance of mechanic and Epoxy resin wire mesh glass can protect against crack of loop;
Epoxy resin wire mesh glass form cast resin alleyway by warp yarn and weft yarn. Epoxy resin wire mesh glass is facility to flow stuff and exclude air bubble;
Epoxy resin wire mesh glass is well compatible with cast resin system, so Epoxy resin wire mesh glass has strong capability of adhesion.
Storage:
Epoxy resin wire mesh glass should be put into the carton after sealed with plastic pocket. Each carton is no less than 70kg, and storage under ventilate, dryness, and Epoxy resin wire mesh glass should be care of fire-proof, moisture-proof, pressure-proof, bake-proof.
Application
Epoxy resin wire mesh glass is mainly used as reinforce insulating in dry cast transformer and in mutual machinery, etc.
Technical Criteria
| No. | Items | Unit | Index | |||||
| 1 | Nominal | mm | 0.6 | 1.2 | 1.6 | 2.0 | 2.4 | |
| 2 | Thickness | mm | 0.1 | 0.2 | 0.2 | 0.2 | 0.3 | |
| 3 | Nominal | g/m2 | 250±50 | 550±50 | 700±50 | 900±50 | 1500±50 | |
| 4 | Resin | % | 20±5 | 20±5 | 18±5 | 18±5 | 18±5 | |
| 5 | Texture Density | MD | mm | 5 | 6 | 5 | 10 | 5 |
| TD | mm | 4 | 6 | 4 | 7 | 4 | ||
| 6 | Bending and Destroying Burden | n | ≥30 | ≥30 | ≥40 | ≥50 | ≥50 | |
| 7 | Tensile and Destroying Burden | n | ≥1000 | ≥1500 | ≥3000 | ≥3000 | ≥1000 | |
| 8 | Surface Breakdown Voltage | kV | ≥18 | |||||
| 9 | Surface Insulation Resistivity | Ω | ≥1 X 1013 | |||||
| 10 | Min. Radius of Curvature(MD) | mm | 100 | 150 | ||||
| 11 | Standard Length | M/reel | 100 | 50/40 | ||||
| 12 | Resin Type | Epoxy Resin | ||||||
| 13 | Standard Width | mm | 1000/1200 | |||||
| 14 | Thermal Class | F/H | ||||||
| 15 | Supplied Size | Supplied with reel, inner diameter is 76mm or 152mm | ||||||
| 16 | Appearance | Smooth, no machinery damage, impurity, and adhesive phenomenon | ||||||
| 17 | Color | Red, burnt almond, natural | ||||||
All kinds of products can be supplied according to the requirement of client
