Hot sale !!! Red Fiberglass Mesh Cloth

FOB Price

USD $0.2 - $15 / Square Meter

100 Square Meters(Min.Order)

Supply Ability 5 Ton / Tons per Month
Port guangzhou chongqing shenzhen shanghai
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Sichuan, China	Brand Name	Guoshun
Model Number	many	Application	Heat Insulation Materials
Weight	75-300g/㎡	Width	1m
Mesh Size	44, 45, 55, 66, 77, 88 ,99, 1010	Weave Type	Plain Woven
Yarn Type	C-Glass	Alkali Content	Alkali Free
Standing Temperature	class F/H

Product Description

Specifications

1. We are engaged in insulating material has been 20 years
2.There are about 300 transformer manufacturers use our products

Hot sale !!! Red Fiberglass Mesh Cloth

Epoxy fiberglass mesh cloth is braided into reticulation structure by fiberglass yarn. and then coated with epoxy resin and baked. Epoxy fiberglass mesh cloth   is used as reinforce orientation on cast resin electric appliance.
Characteristics
Good performance of mechanic and Epoxy fiberglass mesh cloth can protect against crack of loop;
Epoxy fiberglass mesh cloth form cast resin alleyway by warp yarn and weft yarn. Epoxy fiberglass mesh cloth     is facility to flow stuff and exclude air bubble;
Resin coated on Epoxy fiberglass mesh cloth    is well compatible with cast resin system, so Epoxy fiberglass mesh cloth has strong capability of adhesion.

Storage:
Epoxy fiberglass mesh cloth should be put into the carton after sealed with plastic pocket. Each carton is no less than 70kg, and storage under ventilate, dryness, and Epoxy fiberglass mesh cloth should be care of fire-proof, moisture-proof, pressure-proof, bake-proof.
Application
Epoxy fiberglass mesh cloth is mainly used as reinforce insulating in dry cast transformer and in mutual machinery, etc.

Technical Criteria

No.	Items		Unit	Index
1	Nominal		mm	0.6	1.2	1.6	2.0	2.4
2	Thickness		mm	0.1	0.2	0.2	0.2	0.3
3	Nominal		g/m2	250±50	550±50	700±50	900±50	1500±50
4	Resin		%	20±5	20±5	18±5	18±5	18±5
5	Texture Density	MD	mm	5	6	5	10	5
5	Texture Density	TD	mm	4	6	4	7	4
6	Bending and Destroying Burden		n	≥30	≥30	≥40	≥50	≥50
7	Tensile and Destroying Burden		n	≥1000	≥1500	≥3000	≥3000	≥1000
8	Surface Breakdown Voltage		kV	≥18
9	Surface Insulation Resistivity		Ω	≥1 X 1013
10	Min. Radius of Curvature(MD)		mm	100	150
11	Standard Length		M/reel	100	50/40
12	Resin Type			Epoxy Resin
13	Standard Width		mm	1000/1200
14	Thermal Class			F/H
15	Supplied Size			Supplied with reel, inner diameter is 76mm or 152mm
16	Appearance			Smooth, no machinery damage, impurity, and adhesive phenomenon
17	Color			Red, burnt almond, natural

All kinds of products can be supplied according to the requirement of client
