Electrical Crepe Paper
- guangzhou chongqing shanghai shenzhen
- T/T L/C D/P D/A Money Gram Credit Card PayPal
You May Like
Product Details
| Place of Origin | Sichuan, China | Brand Name | Guoshun | |
| Model Number | Insulation paper | Type | Insulation Paper | |
| Material | Composite Polymer | Application | High Voltage | |
| Rated Voltage | high | Tensile Strength | HIGH |
Product Description
Specifications
Has passed ISO9001High quality and competitive price
Quick delivery excellent service
Electrical crepe paper
Crepe paper is composed of insulating paper which is 100% pure imported pulp production, Crepe paper is the special wrinkle processed, Insulation crepe paper has oil soluble performance is very Good, Crepe paper widely used in oil immersed transformer, transformer, Crepe paper reactor winding parts, Crepe paper wire insulation insulate on package parts, so as to improve the insulation Electrical and mechanical properties.
Product specifications
Thickness of Crepe paper is 0.05mm,0.075mm,0.08mm, 0.10mm,0.13mm,2.0mm.
Width of Crepe paper is 25mm.30mm,40mm~960mm.
Storage
Crepe paper should be stored in dry and clean room, not near the fire, heat source or from the su
| No. | Items | Unit | Requirement | |
| 1 | Thickness Tolerance | mm | ±0.05 | |
| 2 | The number of wrinkles | each/10mm long | Code for numerical | |
| 3 | Yield Tolerance | % | Code for numerical ±10 | |
| 4 | A longitudinally extending tensile index | 72-3.1 Type | Nm/g | ≥39 |
| 72-3.2 Type | ≥30 | |||
| 5 | Elongation at break | % | Code for numerical ±15 | |
| 6 | Suction height | MD | mm/10min | ≥7 |
| mm/60min | ≥30 | |||
| TD | mm/10min | ≥20 | ||
| mm/60min | ≥50 | |||
| 7 | Water Content | % | ≤8 | |
| 8 | Ash | % | ≤1 | |
| 9 | The conductivity of water extract | mS/m | ≤10 | |
| 10 | Water extract pH value | - | 6~8 | |
| 11 | Electrical Strength(oil) | mV/m | ≥20 | |
| 12 | Contamination of transformer oil | - | tanδ<0.001 | |
