50 ohm lmr240 with connector of SMA and N rf coustom cable assembly

Specifications

Custom cable assembly
LMR240 cable ISO9001
SMA and N connector Factory price
50 ohm rf cable assembly
custom cable assembly

50 ohm lmr240 with connector of SMA and N rf connector custom cable assembly



RF cable assembly for GSM System, GPS Navigation System, Wireless Communication System, Antennas, Car Radio, Test Equipment

RF cable assembly

 1)APPLICATION :
GSM System
GPS Navigation System
Wireless Communication System
Antennas
Car Radio
Test Equipment
Microwave Components
Data Transmission
Lan System
Satellite Transmission
Aviation Equipment





 2)  COMPATIBLE CONNECTORS
SMA, SMB, SMC, MCX, MMCX, N, FME, TNC, BNC, MINI-UHF, UHF, F, ETC.



 3)   COMPATIBLE CABLES
IMPEDANCE 50Ω / 75Ω / 93Ω
RG405/U, RG402/U, RG316/U, RG223/U, RG188/U, RG179/U, RG174/U, RG142/U,
RG141/U, RG59/U, RG58/U, RG8/U, RG6/U

LMR195, LMR200, LMR240, LMR300 , LMR400, LMR500 , LMR600.

RG213, RG 214



 4)   N-Type Connector:

• Plug ( Male )
• Contact Pin – Brass/Copper, Gold finish
• Impedance-50 Ohms
• Contact Body material –Brass  or equivalent Non –Corrosive
• Insulation Ressitance  5000  M Ohms
• RoHS compliant

5).  Revesrse Polarity SMA Connector:

• Plug (Male) Reverse Polarity
• Contact Pin –Brass /Copper , Gold Finish
• Impedance -50 Ohms
• Contact Body Material-Brass or equivalent Non –Corrosive
• Insulation Resistance  5000 M ohms



6).  LMR -240 Cable

• Impedance -50 Ohms
• Center Conductor –Solid Bare Copper
• Stranded outer Conductor Shield -90% braided
• Insulation –Foam Polyethylene
• RoHs Compliant
• End to End insertion loss of complete cable assy  to be less than 1.5db



  7)Packing

20 feet one roll of rf cable assembly







We  not only provides competitive prices, excellent quality but also helps customers to solve technical problems, improve quality, reduce extra costs, and assist customers to become more competitive.
