Specifications
terminais e conectores1.f type locking terminators
2.Wide bandwidth
3.High return loss
4.Low insertion loss
rg6 coaxial cable F type locking terminais e conectores
| Connector type | F type locking terminator |
| Frequency Range | DC~1GHz |
| Impedance | 75Ω |
| Material | Body: Brass/Aluminum/Zinc alloy |
| Plating: Nickel/Zinc | |
| Insertion Loss | < 0.3dB |
| Power Capacity | > 20 A |
Conductor resistance | Internal ≤ 10 mΩ |
| External ≤ 5 mΩ | |
| Insulating resistance | ≥ 1000 MΩ @DC500V |
| Withstanding voltage | 170V max |
| Vibration | 100m/s2 (10~500Hz) |
| Durability(mating) | ≥500(cycles) |
| Temp.range | -25~+60°C |
| Applicable standard | IEC 60169-24 |
Coaxial cable F port locking terminator
Used to terminate unused ports reducing reflections
Versions available to meet every requirement
Precision high return loss version ensures the most consistent impedance match possible
Prevents signal ingress and egress
- Reduces water migration into open port
