Help CenterCatv Brass f Coaxial Cable Termination Lock
Related Products
-
Catv f Coaxial Cable Locking Wire TerminalsUS$ 0.1 - 0.25MOQ: 5000 Pieces -
Catv Rg6 f Coax Cablelocking Terminal Locking TerminalUS$ 0.1 - 0.25MOQ: 5000 Pieces
-
CATV RG6 Cable F Type Aluminium Locking Cable TerminalUS$ 0.1 - 0.25MOQ: 5000 Pieces
-
Catv HFC f Coax Aluminium Locking TerminatorUS$ 0.1 - 0.25MOQ: 5000 Pieces
-
CATV 75 Ohm Locking Terminator ToolsUS$ 1 - 2MOQ: 100 Pieces
Specifications
brass cable termination lock1) Wide bandwidth for use in broadband systems
2)O ring sealed watertight
3) ROSH,SGS
Connector type |
5/8 |
Vibration |
100m/s2 (10~500Hz) |
Frequency Range |
DC~1GHz |
Durability(mating) |
≥500(cycles) |
Impedance |
75Ω |
Temp.range |
-25~+60°C |
Insertion Loss |
< 0.3dB |
Material |
Shell : Brass |
Power Capacity |
> 20 A |
Conductor: Brass,silver plating |
|
|
Internal ≤ 10 mΩ |
||
External ≤ 5 mΩ |
Insulator: PTFE |
||
Insulating resistance |
≥ 1000 MΩ @DC500V |
O Ring: Silicon Rubber |
|
Withstanding voltage |
170V max |
Applicable standard |
IEC 60169-24 |
- Used to terminate unused ports reducing reflections
- Versions available to meet every requirement
- Precision high return loss version ensures the most consistent impedance match possible
- Prevents signal ingress and egress
- Reduces water migration into open port
catv brass f coaxial cable termination lock and tool
Shipment
All available shipping ways could be applied, by courier, air or sea.
Appointed shipping company or our own forwarders all could be used in shipment.
Full-way tracking the cargos for you before the goods arrive
why do you choose us?
We Consider Our Customers as Our Friends and Families, and We do Believe in the Win-Win Situation
for Building up Long-Term Relationship.
- speciality
DongBei Electronic Element Factory, founded in 1995, is specilized in the design and manufacture of CATV connectors,
electronic connectors, wireless connectors and cable assemblies.
- Dongbei QC Team
Donbei QC team consists of professional people to ensure 100% products high quality.
- Innovation
Provide innovative,stable products and services.
- Customer Satisfaction
Anticipate cusomer needs and exceed their expectations.
