rf Coaxial Female Right Angle Pcb Smb Connector

Name: rf Coaxial Female Right Angle Pcb Smb Connector
Brand: Dongbei
Availability: InStock

FOB Price

US$ 0.1 - 1 / Piece

1000 Pieces(Min. Order)

Port Shanghai
Payment TermsT/T D/P D/A Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Jiangsu, China	Brand Name	Dongbei
Model Number	DB-037	Type	SMB
Application	RF	Gender	Female

Product Description

Specifications

female right angle Pcb Smb Connector
1.Watertight
2.50 ohm For RG8/ RG58 Cable
3.OEM accepted

rf coaxial female right angle Pcb Smb Connector

Connector type	smb male rf connector	Working Voltage	335V max
Frequency Range	0~4GHz (50Ω )	vswr	max 1.30
	0~2GHz(75Ω)
Impedance	50Ω	Temp.range	-65~+165°C
Conductor resistance	Internal ≤ 6mΩ	Material	Shell:brass, gold plating

	External ≤ 1mΩ		male center contacts:brass, gold plating
Insulating resistance	≥ 1000 MΩ		female center contacts: Berylliumcopper,gold plating
Withstanding voltage	750V rms	Applicable standard	IEC 60169-24

Advantage
¹	^{High quality.}^{Strict quality control system, advanced quality inspection center and norms to} ^{ensure our products with excellent quality.}
²	^{Competitive price.} ^{Companies to implement strict cost control, so we can maximize the lower production costs,} ^{the most favorable prices available for you.}
³	^{Extensive production experiences.} ^{Our factory has been more than}^fifteen^{years of history, during which our factory has} ^{accumulated rich production experience.}
⁴	^{Quick and flexible customization capability.} ^{Our factory has separated sample making room , so you just need to give us your sample} ^{or idea then you can receive the actual sample you want.}

SMB is one kind of low power miniature RF coaxial connectors with snap-on coupling mechanism. The characteristic

of connectors is in small volume, light weight, excellent electrical performance, easy to use. They’re widely used in

connection with RF coaxial cable in RF circuit of radio communication, test instruments, meter, radio station,

TV station, the base station of the microwave system.

Information to customer

1.We highly appreciate your any enquiry by email, fax or instant message.

2.We will reply your email or fax within 12 hours.

3.Please fell free to call us at any time if there is any questions

why do you choose us?

We Consider Our Customers as Our Friends and Families, and We do Believe in the Win-Win

Situation for Building up Long-Term Relationship.

speciality

DongBei Electronic Element Factory, founded in 1995, is specilized in the design and manufacture of CATV

connectors, electronic connectors, wireless connectors and cable assemblies.

Dongbei QC Team

Donbei QC team consists of professional people to ensure 100% products high quality.

Innovation

Provide innovative,stable products and services.

Customer Satisfaction

Anticipate cusomer needs and exceed their expectations.
