RF Coaxial Cable Connector Assembly With BNC, SMA, SMB, MCX and MMCX Plug
Specifications
1.high quality,low pricefessional manufacturer
axial cable connector
4.OEM and ODM
5.ISO9001 pass
RF Coaxial Cable Connector Assembly with BNC, SMA, SMB, MCX and MMCX Plug
| Mechanical Characteristics | |
| Characteristic Impedance: | 50Ω |
| Frequency Range: | Flexible: 0-11GHz |
| Semi-rigid cable: 0-18GHz | |
| Withstand Voltage: | ≥2500V,50Hz |
| Working Voltage: | ≤1000V,50Hz (see level) |
| Insulation Resistance: | ≥5000mΩ |
| Contact Resistance: | Inner conductor: ≤1.0mΩ |
| Outer conductor: ≤0.2mΩ | |
| RF leakage(2-3GHZ): | Flexible: ≥90dB |
| 3rd order intermodulation | ≥140dBc |
| Material | |
| Pin conductor: | Brass--Au plated |
| Shell: | Brass--Ternary Alloy (Cu+Zn+Sn) plated |
| Socket: | Phosphor bronze / Beryllium copper--Au/Ag plated |
| Crimping suite: | Copper--Ternary Alloy (Cu+Zn+Sn) |
| Insulator: | PTFE / PFA |
| Sealing: | Silastic |
Applications:
- GSM SystemGPS Navigation System Wireless Communication System
- Antennas
- Car Radio
- Test Equipment
- Microwave Components
- Data Transmission
- Lan System
- Satellite Transmission
- Aviation Equipmen
Dongbei QC Team
- Donbei QC team consists of professional people to ensure 100% products high quality.
Contact Us
- We highly appreciate your any enquiry by email, fax or instant message.
- We will reply your email or fax within 12 hours.
- Please fell free to call us at any time if there is any questions.
Transportation
- All available shipping ways could be applied, by courier, air or sea.
- Appointed shipping company or our own forwarders all could be used in shipment.
- Full-way tracking the cargos for you before the goods arrive.
How to place order?
- send you inquiry to get catalog.
- choose the models you would like to buy.
- confirm the total quantity&freight.
- Do the payment.
