RF Male/female Assembly Jumping Cables Pigtail

Name: RF Male/female Assembly Jumping Cables Pigtail
Brand: DB Connector
SKU: 124547171

US$ 0.5 - 5 MOQ: 1000 Pieces

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

DB Connector

Model Number:

DB jumper cable

Yangzhou Dongbei Electronic Equipment Factory

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name DB Connector

Model Number DB jumper cable

Specifications

RF male/female jumping cables
1.small-sized thread coupling
2.wide frequency range
3.excellent performance
4.ISO9001 pass

RF male/female assembly jumping cables pigtail

Mechanical facts
characteristic Impedance	50Ω
frequency range	0-18GHz
withstanding voltage	750~1500V,50Hz
working voltage	250~500 v,50Hz (see level)
working voltage	65~125 v,50Hz (height 21000m form sea level)
insulation resistance	≥5000mΩ
contact resistance	inner conductor ≤3mΩ
contact resistance	outer conductor ≤2.5mΩ
RF leakage(1GHZ)	flexible ≥60dB
RF leakage(1GHZ)	semi-rigid cable ≥100dB
Material facts
pin conductor	brass/beryllium copper--gold plated
body/outer conducter	beryllium copper--gold plated
	stainless steel--passivation
	brass---gold plated/ternary alloy(Cu+Zn+Sn)
	phosphor bronze---gold plated
plug	beryllium copper/phosphor bronze--gold plated
crimping sleeve	brass--gold plated
Insulator	PTFE / PFA
sealing ring	silica rubber

Features & Benefits

Broadband performance DC to 18 GHz with low reflection stainless steel construction and ¼ - 36 threaded coupling offers high performance in a compact design.
Low cost Commercial Grade (Brass SMA) available in nickel or gold plating which provides approximately 30% cost reduction with 250 mating cycles.
Available for .085" and .141" diameter semi-rigid cables and all the standard flexible cables including double shielded RG-316.
Phase Adjustable SMA connectors provide ease of mechanical screw adjustments, compared to the delays and expense of laborious cable-trimming.
