Specifications
bnc female cannon connectors with wire1) Insulator:PTFE/POM
2) Female Contact: Beryllium copper
3) Certification:ROHS
bnc female flange mount cannon connectors with wire from dongbei factory
| Connector type | bnc female cannon connectors | Working Voltage | 500V max |
| Frequency Range | DC-4GHz |
vswr | max 1.3 |
| Impedance | 50Ω | Temp.range | -65~+165°C |
| Conductor resistance | Internal ≤ 3mΩ | Material | Shell:copper, nickel plated |
| External ≤ 2mΩ | Nut:brass, nickel plated | ||
| Insulating resistance | ≥ 5000 MΩ | pin:brass,gold plating | |
| Withstanding voltage | 1500V rms | Usability | 500 Cycles min |
material specification:
Parts Name |
Material |
Finish |
|
Center Contact |
Male |
Brass |
3u" Gold or Silver per requirement |
Female |
BeCu or P. Bronze |
3u" Gold or Silver per requirement |
|
Body, Metal Parts |
Brass |
Nickel |
|
Insulators |
PTFE, Delrin, PBT |
None |
|
Clamp Gaskets |
Silicone rubber |
None |
|
Crimp Ferrules |
Annealed copper |
Nickle or Silver per requirement |
|
♥ Antennas
♥ Radios
♥ Broadcast
♥ Telecom
- Universal for standard Manfactured of high quality brass with nickel plating of superior protection against v-corrosion
- Bayonet coupling, small size and low cost.
- 50Ω and 75Ω are available and intermateable
our main market: north America South America Eastern Europe
Southeast Asia Africa Oceania
Mid East Eastern Asia Western Europe
Central America Southern Europe South Asia
PS:
- OEM are welcome
- high quality but low price
- We have many types connector for your choosing, if you have any query please fell free to contact me, I am glad service for you
- We have professional team to service for you, please tell me your detail information then I will offer you the right products you need
other bnc connector:
Dongbei QC Team
Donbei QC team consists of professional people to ensure 100% products high quality.
Contact Us
We highly appreciate your any enquiry by email, fax or instant message.
We will reply your email or fax within 12 hours.
Please fell free to call us at any time if there is any questions.
Skype:camille.wu3
Transportation
All available shipping ways could be applied, by courier, air or sea.
Appointed shipping company or our own forwarders all could be used in shipment.
Full-way tracking the cargos for you before the goods arrive
