CATV Classic 75ohm F Twist on Connector

CATV Classic 75ohm F Twist on Connector thumbnail-1
CATV Classic 75ohm F Twist on Connector photo-1
Negotiable MOQ: 5 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
DB
Model Number:
OPT-TF-1
Contact Supplier Request Quote Chat Now
Yangzhou Dongbei Electronic Equipment Factory
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Jiangsu, China
Brand Name DB
Model Number OPT-TF-1
Type F
Application RF
Gender Female

Specifications

F port Twist on Connector
1. watertight available
2. fast installtion
3. brass or zinc alloy /nickle or zinc plating

Characteristics:

  • Bandwidth: 0 MHz to 3 GHz
  • Impedance: 75 Ohms (nominal)
  • Return Loss: Better than –30 dB to 3 GHz
  • Operating Voltage: 90 V (at 60 Hz continuous AC)
  • Operating Temperature: -40°F to +140°F
  • Cable Retention:60% Braid –50 lbs. Minimum, Quad Shield –100 lbs. Minimum
  • Cable Range: 60% -Quad Shield, PE, PVC Jacket

Applications:

  1. Telecom
  2. Antennas
  3. Radios
  4. Broadcast
  5. Coaxial cable
  6. CCTV

Parameter sheet :

Temperature Range

-40~+60 PE cable -40~+85)

Impedance

75ohm

Frequency Range

0-1G

Center conductor withdrawl force

0.49N

Working Voltage

170Max

Contact Resistance

Inner:6miliohms max

Outer:1 miliohms max

VSWR

straight:1.2max,R/A:1.3max

Insulation resistance

1000 miliohms

Withstand Voltage(At the sea level)

750V

Durability

500cycles

Authentication

ISO9001: 2000, 14001: 2004 RoHS

APPLICABLE STANDARD

IEC169-15  MIL-C-39012

CATV Classic 75ohm F Twist on Connector



We have many types connectors for your choosing, if you have any query, please fell free to contact me, I am glad to service you.
