Rg6 f Compression Fitting Connector
- shanghai
- T/T D/P D/A Money Gram Credit Card
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | db | |
| Model Number | OPT-CPS-7 | Type | F | |
| Application | RF | Gender | Female |
Product Description
Specifications
compression fitting connector1brass/zinc
2Plating: nickel
3wide frequency range,nice looking
4wateproof
rg6 f compression fitting connector
Impedance: 75Ω
Temperature Range: -55~+155 oC
Frequency Range: DC~7.5GHz
Insulation resistance : ≥ 10000 M Ω
Average power 3kw max
Center conductor retention force ≥6N
Insulator: PTFE
Body: brass & zinc and nickel plated
Pin contact: brass &nickle plated
Crimp ferrule: copper alloy & nickel plated
o-ring sealing: sllicone rubber.
---------------------------------------------------------------------------------------------------------
· wide operating band - up to 3 GHz,
· waterproof termination of the cable,
· resistance to corrosion - made of non-ferrous metals and highest-quality dielectric,
· very low loss in the whole operating band,
· perfect matching to the transmission line within the whole operating band,
· simple and quick assembly: longitudinal compression,
· properly compressed connection is highly resistant to break, due to dual compression rings,
· monolithic construction,
· quick and easy assembly, as well as stability of operation of the equipment are really worth the price.
