Help CenterF RG6 Connector
US$ 0.1 - 0.3
MOQ: 10000 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
DB
Model Number:
OPT-CPS-7
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Dongbei 75Ohms Splice Barrel Double Female ConnectorNegotiableMOQ: 10000 Pieces -
CATV Drop Coaxial Cable Crimp f Type Coaxial ConnectorsUS$ 0.04 - 0.2MOQ: 5000 Pieces
-
CATV Rg59,rg6 Male F Twist on ConnectorUS$ 0.04 - 0.2MOQ: 5000 Pieces
-
CATV Drop Coaxial Cable f Crimp ConnectorUS$ 0.04 - 0.2MOQ: 5000 Pieces
-
Waterproof Maler Crimp Connector Rg6 FUS$ 0.07 - 0.26MOQ: 2000 Pieces
Place of Origin
Jiangsu, China
Brand Name
DB
Model Number
OPT-CPS-7
Type
F
Application
RF
Gender
Male
Specifications
F RG6 commpression connector1.RG6 connector O ring sealed waterproof
2.Material:Brass
3.RG6 connector High quality
| Connector type | F-male 3/8-32 UNEF | Working Voltage | 170V max |
| Frequency Range | DC~1GHz | Vibration | 100m/s2 (10~500Hz) |
| Impedance | 75Ω | Temp.range | -25~+60°C |
| Conductor resistance | Internal ≤ 10 mΩ | Material | Shell:Copper, Bright nickel plating |
| External ≤ 5 mΩ | Nut:Copper, Bright nickel plating | ||
| Insulating resistance | ≥ 1000 MΩ@ DC500V | O ring:Silicon rubber | |
| Withstanding voltage | 500V rms | Applicable standard | IEC 60169-24 |
- Manfactured of high quality brass with nickel plating of superior protection against v-corrosion
- Designed to be watertight for outdoor applications
- Offer excellent RFI shielding properties
- easy-grip free-spinning nut for fast installation and installer comfort
- For standand .tri-shield or quad-shield RG6 coaxial cable
Dongbei QC Team
Donbei QC team consists of professional people to ensure 100% products high quality.
Contact Us
We highly appreciate your any enquiry by email, fax or instant message.
We will reply your email or fax within 12 hours.
Please fell free to call us at any time if there is any questions.
Transportation
All available shipping ways could be applied, by courier, air or sea.
Appointed shipping company or our own forwarders all could be used in shipment.
Full-way tracking the cargos for you before the goods arrive
