BNC male with spring waterproof connector cable
USD $0.1 - $0.4
/ Piece
1000 Pieces(Min.Order)
- 100000 Piece / Pieces per Month
- Shanghai
- T/T D/P D/A Credit Card
You May Like
Product Details
Place of Origin: | Jiangsu, China | Brand Name: | DB Connector | Model Number: | DB8080 |
Type: | BNC | Application: | RF | Gender: | Male |
Product Description
Specifications
1.BNC waterproof connector cable2.Brass Plating: nickel
lder connector
4.factory price
5.ISO90001 approved
BNC male with spring waterproof connector cable
Features:
- Bayonet coupling, small size and low cost.
- 50Ω and 75Ω are available and intermateable
- Various options for different applications
Applications:
- Antennas
- Broadcast
- Radios
- Telecom
Electronical Specifications:
Impedance | 50Ω | 75Ω |
Frequency Range | 0-4 GHz | 0-2 GHz |
Working Voltage | 500 VRMS max. at sea level | 500 VRMS max. at sea level |
Dielectric Withstanding Voltage | 1500 VRMS min. at sea level | 1500 VRMS min. at sea level |
VSWR | Straight: 1.3 max., R/A: 1.5 max. | Straight: 1.3 max., R/A: 1.5 max. |
Contact Resistance | Center Contact: 3 milliohm Max. | Center Contact: 3 milliohm Max. |
Outer Contact: 2 milliohm Max. | Outer Contact: 2 milliohm Max. | |
Insulator Resistance | 5000 megaohms min. | 5000 megaohms min. |
Material Specifications:
Parts Name | Material | Finish | |
Center Contact | Male | Brass | 3μ" Gold or Silver per requirement |
Female | BeCu or P. Bronze | 3μ" Gold or Silver per requirement | |
Body, Metal Parts | Brass | Nickel | |
Insulators | PTFE, Delrin, PBT | None | |
Clamp Gaskets | Silicone rubber | None | |
Crimp Ferrules | Annealed copper | Nickle or Silver per requirement |
Note: Other Material/Finish is available on request
Dongbei QC Team
- Donbei QC team consists of professional people to ensure 100% products high quality.
Contact Us
- We highly appreciate your any enquiry by email, fax or instant message.
- We will reply your email or fax within 12 hours.
- Please fell free to call us at any time if there is any questions.
Transportation
- All available shipping ways could be applied, by courier, air or sea.
- Appointed shipping company or our own forwarders all could be used in shipment.
- Full-way tracking the cargos for you before the goods arrive.
How to place order?
- send you inquiry to get catalog.
- choose the models you would like to buy.
- confirm the total quantity&freight.
- Do the payment.
Contact Us
- Yangzhou Dongbei Electronic Equipment Factory
- Contact nameDonald Chen
- Phone86-571-81110240
- Address707-708room , zhongxun building ,Xihu district Hangzhou,Zhejiang
