90 Degree Right Angle Male and Female Electrical Connector Adapter
US$ 0.1 - 0.4
MOQ: 1000 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
DB Connector
Model Number:
DB8056
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
High Quality 4mm Gold Plated Connectors Audio AdapterUS$ 0.1 - 0.4MOQ: 1000 Pieces -
Mmcx to Sma Cable Assembly,pigtail,sma Jumper CableUS$ 0.1 - 1.5MOQ: 1000 Pieces
-
Audio Converter Straight Type Adapter Rca Female Jack to Bnc Male PlugUS$ 0.1 - 0.4MOQ: 3000 Pieces
-
Pal Male to f Female RF Connectors AdaptersUS$ 0.1 - 0.5MOQ: 3000 Pieces
-
50ohm or 75ohm Bnc Male to Rca Female JackUS$ 0.1 - 0.4MOQ: 5000 Pieces
Place of Origin
Jiangsu, China
Brand Name
DB Connector
Model Number
DB8056
Type
Adapter
Application
RF
Gender
Male
Specifications
1.wide frequency range2.good performance
3.male and female electrical connector
4.High quality,low price
5.ISO900 pass
90 degree right angle male and female electrical connector adapter
| F connector | |||
| Impedance | 75Ω | Frequency range | 0~2GHz |
| Resistanc | Inner conductor ≤2.0mΩ | External resistance | ≤0.2mΩ |
| Insulation Resistanc | ≥5000MΩ | Medium pressure | 1500V |
| Durability | 500 times | Center Pin: | Gold-plated pure Copper |
| Materials | Teflon | Frequency response: | DC to 8 MHz |
| Attenuation | 0.5dB typ | Environmental | -10°C to +70°C |
| Storage | -30°C to +70°C | Humidity | 0 to 95% |
| Wire Type | Unshielded Cat-5 or above twisted pair wire | Category Type | 5or better |
| DC Loop Resistance | 52 ohms per 1,000 ft | Material | ABS Zinc Alloy |
| Withstand Voltage | 1500V rms | Center Contact | ≤ 1.5 ohm |
Note: These characteristics are typical but may not apply to all connectors.
Featues:
- Manufactured of high quality brass with nickel plating for superior protection against V-corrosion
- Designed to be watertight for outdoor applications
- Patented internal crimp design offers excellent RFI shielding properties
- Unique ridge-patterned internal sleeve presses firmly against cable jacket, sealing connector against moisture at the back end
- Easy-grip free-spinning nut for fast installation and installer comfort
- Universal for standard, tri-shield or quad-shield RG6 coaxial cable
Applications:
- Telecom
- Antennas
- Radios
- Broadcast
- Coaxial cable
- CCTV
Dongbei QC Team
- Donbei QC team consists of professional people to ensure 100% products high quality.
Contact Us
- We highly appreciate your any enquiry by email, fax or instant message.
- We will reply your email or fax within 12 hours.
- Please fell free to call us at any time if there is any questions.
Transportation
- All available shipping ways could be applied, by courier, air or sea.
- Appointed shipping company or our own forwarders all could be used in shipment.
- Full-way tracking the cargos for you before the goods arrive.
How to place order?
- send you inquiry to get catalog.
- choose the models you would like to buy.
- confirm the total quantity&freight.
- Do the payment.
