bnc female to bnc female connector adapter
- 50000 Piece / Pieces per Month
- Shanghai
- T/T Credit Card
Product Details
Place of Origin: | Jiangsu, China | Brand Name: | DongBei | Model Number: | DB8085 |
Type: | Other, Adapter, BNC double female | Application: | RF | Gender: | Female |
Product Description
Specifications
bnc female connector1.High quality
2.Best serve
3.Competitive prices
4.18 years factory experience
bnc female to bnc female connector adapter
Temperature Range | -40~+60°C | |
Impedance | 75 Ω ,50Ω | |
Frequency Range | DC~4GHz | |
Working Voltage | 500V max(rms) | |
Withstand Voltage | 1500V rms | |
Contact Resistance | Center Resistance : ≤ 1.5 mΩ | Outer Contact : ≤ 1 mΩ |
Insulation Resistance | ≥ 5000 MΩ | |
VSWR | Straight : ≤ 1.22 | Right Angle : ≤1.30 |
Durability (mating) | ≥ 500 cycles |
*** BNC series are one kind of cards of thing the mouth join the radio frequency coaxial connection device.
It joins rapidly, keeps in touch with the characteristic such as being reliable,
apply to the radio equipment and electron tube instrument field and join the coaxial cable of the radio frequency extensively.
* We have various types connector and an professional ,experienced service team.
* Welcome to login our website check more products information.
Dongbei QC Team
Donbei QC team consists of professional people to ensure 100% products high quality.
Contact Us
We highly appreciate your any enquiry by email, fax or instant message.
We will reply your email or fax within 12 hours.
Please fell free to call us at any time if there is any questions.
Transportation
All available shipping ways could be applied, by courier, air or sea.
Appointed shipping company or our own forwarders all could be used in shipment.
Full-way tracking the cargos for you before the goods arrive.
Contact Us
- Yangzhou Dongbei Electronic Equipment Factory
- Contact nameDonald Chen
- Phone86-571-81110240
- Address707-708room , zhongxun building ,Xihu district Hangzhou,Zhejiang
