Home > Products > Roof Mounting System > solar tile roof mounting/bracket
solar tile roof mounting/bracket
- 1500 Set / Sets per Month
- shanghai
- T/T
Product Details
Place of Origin: | Zhejiang, China | Grade: | 6000 Series | Temper: | O-H112 |
Application: | Other, panel bracket for PV module installation | Shape: | T - Profile | Alloy Or Not: | Is Alloy |
Model Number: | CY-ZJ08 | Brand Name: | CY solar tiles |
Product Description
Tile roof mounting bracket
The wide range of different components and systems makes it possible to fasten almost any module configuration on almost any roof.
you can choose panels arrangement according to your roof size . With our high-value and elaborated components, quick mounting times and reliable durability including structural analysis can be taken for granted.
We provide both roof-parallel and elevated solutions for pitched roofs. The clamp kit and the various roof hooks can be high pre-assembly and make the installation easy and quick to save your labor cost and time
characterized by:
1.Space high utilization
2.Cost Saving
3. Easy installation.
4.Strong to support
5.Maintenance free.
6.Various kinds of roof hook to satify the different requirements.
Technical characteristics:
Installation site | slope roof |
Applicition | tile roof |
Wind resistance | 60m/s |
Snow load | 1.4KN/m2 |
Solar panel type | with or without frame |
Components arrangement | horizontal or vertical |
International criteria | eligible |
Support track | aluminum alloy extrusion |
Color | natural color |
Quality warranty | 10 years |
More than 30% of components would been assembled in factory, to save your time and cost of installation.
Drawings and installation manual would be contained in the offer.
Factory direct sales, faster delivery and safety package
Contact Us
- Haining Chuangyuan Solar Energy Technology Co., Ltd.
- Contact nameGuohao Zhu
- Phone86-573-87788269
- AddressNo.7 Luotang Street, Xieqiao Town,Haining City Jiaxing,Zhejiang
