55" Large-screen LED Touch Panel, Interactive Display Board, Infrared LCD Touch Panel
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Wanin
Model Number:
TL5515E
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
70" Large-screen LED Interactive Board / Touch PanelUS$ 2,500 - 4,000MOQ: 10 Pieces -
LED Multi Touch Screen Monitor TV, LED Interactive Whiteboard/ Large LED Touch PanelNegotiableMOQ: 1 Piece
-
LED Multi Touch Screen Monitor, Touch Screen Led Tv, LED Interactive WhiteboardNegotiableMOQ: 1 Piece
-
55" Touch Screen MonitorNegotiableMOQ: 1 Piece
-
LED Interactive White BoardNegotiableMOQ: 1 Piece
Place of Origin
Zhejiang, China
Brand Name
Wanin
Model Number
TL5515E
Specifications
Large-screen LED , interactive touch board, interactive smart board,which integrates LED TV and touch screenReal two touch
55"/ 65"/ 70" Large-screen LED , interactive touch board, interactive smart board
is a new generation display equipment, which integrates LED TV and touch screen,it is a one stop solution which adds interactivity and energies to any training, learning, work reporting environment to improve the efficiency and effectiveness of communication.
SPECIFICATIONS:
| Model | TL-5515E | TL-6515E | TL-7003 |
| Display | LED | LED | LED |
| Diagonal size | 55" | 65" | 70" |
| Displaying surface | 47.6"(H)×26.8"(V) | 56.2"(H)×31.6"(V) | 70"(H)×34.3"(V) |
| Displaying rate | 16:09 | 16:09 | 16:09 |
| Effective pixels | 1920×1080 | 1920×1080 | 1920×1080 |
| Brightness | ≥500cd/m² | ≥500cd/m² | ≥500cd/m² |
| Viewing angle | >176° | >176° | >176° |
| Contrast | 5000:1 | 5000:1 | 5000:1 |
| Reaction time | 5ms | 5ms | 5ms |
| TV function | Support all kinds of analog and digital TV | Support all kinds of analog and digital TV | Support all kinds of analog and digital TV |
| Touch Device | |||
| Sensor | Infrared | Infrared | Infrared |
| Resolutions | 4096×4096 | 4096×4096 | 4096×4096 |
| Multi-touch | 2 Points | 2 Points | 2 Points |
| Response speed | ≤16ms | ≤16ms | ≤16ms |
| Positioning accuracy | ±2 mm | ±2 mm | ±2 mm |
| Writing tool | Any object with diameter above 5mm | Any object with diameter above 5mm | Any object with diameter above 5mm |
| Working temperature | -5°C ~ +40°C | -5°C ~ +40°C | -5°C ~ +40°C |
| Input Terminals | |||
| HDMI | ×2 | ×2 | ×2 |
| VGA | ×3 | ×3 | ×3 |
| YPbPr | ×1 | ×1 | ×1 |
| S-VIDEO | ×1 | ×1 | ×1 |
| VIDEO | ×2 | ×2 | ×2 |
| AUDIO | ×3 | ×3 | ×3 |
| RF IEC | ×1 | ×1 | ×1 |
| RS232 | ×1 | ×1 | ×1 |
| MIC | ×1 | ×1 | ×1 |
| USB(Multimedia) | ×1 | ×1 | ×1 |
| Output Terminals | |||
| VGA | ×1 | ×1 | ×1 |
| VIDEO | ×1 | ×1 | ×1 |
| SPDIF | ×1 | ×1 | ×1 |
| AUDIO | 2 | 2 | 2 |
| USB (Touch) | USB Slave Touch Out×1 | USB Slave Touch Out×1 | USB Slave Touch Out×1 |
|
Embedded PC (Optional) |
|||
| CPU | Intel G620 2.6GHz/Intel i3 2100 3.1GHz | ||
| Memory | 2G | 2G | 2G |
| Main board IC | Intel H61 | Intel H61 | Intel H61 |
| Hard disk | 320G/500G | 320G/500G | 320G/500G |
| Inputs and outputs | LAN×1,USB≥4 | ||
| Other | |||
| Power consumption | 220W | 250W | 400W |
| Dimensions | 1367×826×123.5(mm) | 1589x959x122.4(mm) | 1711x1033x141.3(mm) |
| Weight | 50KG | 60KG | 110KG |
| Installation | Wall mount,Moving stand(optinal) | ||
WANIN has been the leading vender in China's education electronics market for over a decade, and is now gaining reputation in USA , EU as well as majority of Asian countries. We take great pride in offering quality products to our worldwide customers and we are now looking forward to the opportunity of serving you.
