China professional belt conveyor supporting roller
Henan Joinrise are a profesional manufacture of specially producing all kinds of Conveyor idlers & rollers & pulley, including Carrying idlers/roller ,Impact idlers/roller, Return idlers/roller, Training idlers/roller, Guiding idlers/roller, and Conveyor pulley & different types of Frame.
The function of Conveyor idler/roller is supporting the conveyor and conveying materials, therefore, the quality of conveyor idler/roller is particularly important.
Parallel conveyor belt roller is used for supporting the weight of the basecoat rubber belt. It consists of shell, axis, bearing, bearing pedestal and seal ring.
Diameter |
Length |
Bearing |
89 |
600 750 950 |
4G204 4G205 |
108 |
1150 1400 1600 |
4G205 4G305 4G306 |
133 |
1150 1400 1600 |
4G305 4G306 |
159 |
1400 1600 |
4G305 4G306 |
|
|
|
|
|
|
Roller Dia (mm) |
Length Scope (mm) |
Belt Wide (Min-Max) |
Roller's Weight (kgs) |
89 |
950 |
800 |
19 |
108 |
950 |
800 |
23 |
133 |
950 |
800 |
30 |
108 |
1150 |
1000 |
27 |
133 |
1150 |
1000 |
42.1 |
159 |
1150 |
1000 |
44.3 |
108 |
1400 |
1200 |
30.3 |
133 |
1400 |
1200 |
4..7 |
159 |
1400 |
1200 |
55.2 |
108 |
1600 |
1400 |
40 |
133 |
1600 |
1400 |
44 |
159 |
1600 |
1400 |
57 |
| The shell cutting of the conveyor roller | |
|
The welding of the conveyor roller |
| The test of the conveyor roller | |
1. Henan Joinrise Mining Equipment Manufacture Co.,Ltd is a fixed-point production facility for the original China Coal Mining Machinery Industrial Department.
2. It is one of the first organizations to be awarded the national Safety Sign Approval Certification.
3. It has passed ISO9001 International Quality System Certification, acquired the Industrial Products Manufacturing License.
4. It is a professional manufacturer of belt conveyors and have boast a technical and engineering team with rich practical experience.
1) We can design the conveyor roller as customer requested.
2) One-year warranty for free.
3) Any problems during use, you can freely contact with us by email or by telephone.
