low iron tempered glass
What is it?
Tempered glass, has a very good performance of anti-curve, anti-hitting, 3 to 6 times better than normal glass. It can afford pressure over 95MPa on the surface. It has high stability even under temperature changing from 200 to 300. While normal glass can only afford change of 70-100. It becomes small sand shape if is broken under big force, which guarantee safety and less loss. We are with largest jumbo size flat/curved tempered glass processing ability. Toughened glass is good choice for safety.
Advantages:
3 to 6 times more resistant to breakage than normal glass
If the glass does break, there is far less risk of injury from broken pieces
Application:
External use of show windows, doors, shopfronts in offices, houses, shops etc.
Interior glass screens, partitions, balustrades etc.
Shop display windows, showcases, display shelves etc.
Furniture, table-tops etc.
Production Range:
Max. Size:3600mmx18000mm (Extra Large tempered glass)
Min. Size: 100mmx100mm
Thickness Range: 3mm-19mm
Color: Clear, low iron, blue, green, bronze, black color, low -e, reflective tempered glass
Main Processed glass products:
1,Heavy Tempered Glass.
2.Oversized Glass Available(Tempered and Laminated)
3.Hurricane Resistant Glass(SGP and Solutia Certified)
4.Heat Soaked Glass
5.Laminated Glass(Billet and Custom)
6.Spandrel Glass-Spankote,Ceramic Frit/Opacicoat.
7.Insulated Low-e Glass.
8.Heavy Structural Glass
9.Bent Glass
10.Bullet Resistant Glass.
Thickness |
Visible Light Transmittance |
Visible Light Reflectivity |
Solar Transmittance |
Solar Reflectivity |
Visible-infrared Transmittance |
Ultraviolet Transmittance |
2mm |
90.69 |
8.3 |
87.22 |
7.9 |
84.15 |
83.44 |
2.5mm |
90.47 |
8.3 |
86.14 |
7.8 |
82.31 |
81.97 |
2.8mm |
90.34 |
8.3 |
85.51 |
7.7 |
81.22 |
81.15 |
3mm |
90.25 |
8.3 |
85.09 |
7.7 |
80.51 |
80.62 |
3.2mm |
90.17 |
8.3 |
84.67 |
7.7 |
79.80 |
80.11 |
4mm |
89.82 |
8.3 |
83.04 |
7.6 |
77.03 |
78.18 |
5mm |
89.39 |
8.2 |
81.07 |
7.4 |
73.71 |
76.02 |
6mm |
88.96 |
8.2 |
79.17 |
7.3 |
70.54 |
74.08 |
8mm |
88.31 |
8.1 |
76.51 |
7.1 |
66.14 |
70.60 |
10mm |
87.47 |
8.1 |
73.61 |
6.9 |
61.56 |
67.15 |
12mm |
86.25 |
8.0 |
68.53 |
6.6 |
53.09 |
66.23 |
Physical Properties:
Density |
2.5 g/cm3 |
Linear Coefficient of expansion:25-300℃ |
8.6×10-6/°C |
Softening Point |
723°C |
Annealing Point |
544°C |
Strain Point |
504°C |
(-18~66℃)Hemispherical emissivity |
0.84 |
Specific Heat(0-100℃) |
0.205 |
Thermal conductivity(49℃)(watt/m2/k) |
36.9 |
Mechanical Properties:
Modulus of elasticity(Young’s modulus) |
73.1Gpa |
Modulus of rupture (tensil strength -ultimate) |
41.4 Mpa |
Knoop hardness |
470kgf/mm2 |
Tempered Glass (Regular thickness& approximate container loading capacity)
|
Container |
1X20GP |
1X40GP |
1X40GP |
|
Loading capacity |
17.5T |
22.5T |
22.5T |
Thickness |
Kg/m² |
Square meter |
Square meter |
Square meter |
3mm |
7.5 |
2240 |
2840 |
2840 |
4mm |
10 |
1680 |
2130 |
2130 |
5mm |
12.5 |
1344 |
1704 |
1704 |
6mm |
15 |
1120 |
1420 |
1420 |
8mm |
20 |
840 |
1065 |
1065 |
10mm |
25 |
672 |
852 |
852 |
12mm |
30 |
560 |
710 |
710 |
15mm |
37.5 |
448 |
568 |
568 |
19mm |
47.5 |
354 |
448 |
448 |
Note |
All the above data is just for your reference
|
|||
Production workshop
1.putting pearl wool between glass.
2.strong wooden crates with steel banding for export
3.Good relationship with shipping Co.
4.Professional team of export wooden box production.
Henan Fuxin Group is professional supplier of glass of processing.it covers an area of 10,000 square meters,200 employees.
Our main products:Tempered Glass(Toughened Glass) laminated glass,insulated glass,Low-e glass,fire proof glass,bulletproof glass,ceramic frit laminated glass,Security Glass,Decorative glass,silk printing glass ,hardware fitting of glass installation,Aluminum profile etc.Max Size:3300mm×16000mm.Min Size:300mm×300mm.and provide service of glass installation solution.
Looking forward to build great relationship with you.
1. 10 years experiences on glass manufacturing and exporting.
2. The only large plate glass production enterprise in China,we are factory can provide good quality and best price.
3.Unique designed strong wooden cases, solving the problems of breakage.
4. Full range of process glass supply, offering one-stop purchase.
6. Professional sales team, offering personalized and dedicated services.
Q;What are your main products?
A;Tempered Glass(Toughened Glass) laminated glass,insulated glass,Lowe glass,fire proof glass,bulletproof glass,ceramic frit laminated glass,Security Glass,Decorative glass,silk printing glass ,hardware fitting of glass installation,Aluminum profile etc.
Q;Can you provide what size of glass?
A;Max Size:3300mm×16000mm,Min Size:300mm×300mm.
Q;Can you provide what thickness of flat glass?
A;3mm,5mm,6mm,8mm,10mm,12mm,15mm,19mm,22mm.
Q;Can you provide what kind of film and thickness?
A;PVB Film:0.38mm.0.76mm.1.52mm.2.28mm.SGP Film:0.89mm,2.28mm.
Q;What is the payment method?
A;T/T,L/C
Q:How to get a quotation?
A:We need some information,such as size,color ,thickness,quantity,edge, etc.
Q; How long is the delivery time ?
A;10~20days.
