7.5KWH, 48V 150AH Lifeop4 battery for Solar/wind turbine/ Energy Storage System
Product advantages:
1. Long cycle life (2000 cycles) is several times greater than Ni-MH, Ni-Cd or lead-acid.
2. No toxic, or polluting material(such as lead, cadmium, mercury) is contained in lithium battery, which is a kind of green battery.
3. High safety. LiFePO4 is an intrinsically safer cathode material than Lithium-ion since exothermic reactions can not occur in batteries based on this material LiFePO4 cells do not incinerate or explode under extreme conditions.
4. Good performance in high-current discharge cycles. We can design different capacity and size according to your demands.
For many applications, our battery systems result in significantly lower total cost of ownership over lead acid because lighter-weight, longer-life batteries means fewer replacements, reduced maintenance and service costs, less shipping and material handling costs, and lower total inventory carrying costs.
Detail Specifications:
| MODEL# | 48/5K-40/70 | 48/7.5K-40/70 | 48/10K-80/150 |
| DATASHEET | |||
| Intergrated BMS/PCM | Optional | ||
| Output Capacity(Wh), D0D=80% | 5K | 7.5K | 10K |
| Nominal voltage (V) | 48 | 48 | 48 |
| Nominal capacity (Ah) | 100 | 150 | 200 |
| System configuration | 100x1 battery |
150x1 battery |
200x1 battery |
| Dimensions (L*W*H in mm) | |||
| Constant charge/ discharge current (A) | 40 | 80 | 80 |
| Maximum charge/ discharge current (A) | 70 (15 seconds) | 70 (15 seconds) | 70 (15 seconds) |
| Standard Charge Voltage (V) | 58.4 | 58.4 | 58.4 |
| Discharge cut-off voltage (V) | 50.4 | 50.4 | 50.4 |
| Approx. Weight (Kg) | 50 | 80 | 100 |
| WORKING CONDITION |
Operating temp. : -20 ~ 60℃ Humidity : max 95% |
||
| ENCLOUSURE | |||
| Common characteristics |
Material : Iron Colour : Black or Ivory White |
||
| Battery connector |
Anen Connector or according to customers' requirement |
||
| STANDARDS | |||
| Safety | EN61000-6-1, EN61000-6-3 | ||
