Product Details
Condition: | New | Place of Origin: | Zhejiang, China | Brand Name: | Finding or OEM |
Model Number: | Pressing and bending machine | Machine Type: | Beading Machine | Raw Material: | Sheet / Plate Rolling |
Material / Metal Processed: | Stainless Steel | Power: | Hydraulic | Automation: | Automatic |
Extra Services: | Welding / Brazing | Certification: | CE | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
Good qualityComprehensive sevice
Good price
CE certificate
20 years experience
Detail specification:
Machine's name: Pressing and bending machine
This kind of machine is used for curving the corrugated steel sheet which fabricated already by steel roll forming machine.
The radius of curving sheet can be adjustable.
No. | Item | Parameter |
1 | Hydraulic Station Motor | 4 KW |
2 | Material Punching Mould | 40Cr, Surface quenching and nitrifying |
3 | Width | As customer 's drawing |
4 | Yield stress | 240Mpa TO 550Mps |
5 | Thickness of Sheet(mm) | 0.3 - 0.7 mm |
6 | Operation | Automatic |
7 | Installation | Horizontal Tpye |
8 | Voltage | 380V 50hz or as your requirment |
9 | Productivity | 1-5m/min |
10 | Radius | Minimum 250 mm to 350 mm |
11 | Power of Hydraulic Station | 11 KW |
12 | Power of stepping motor | 0.75KW |
13 | Material of moulds | Cr12, Surface hardening & nitridation |
14 | Others | curve beautifully and curve wide radius |
No scratch on the surface | ||
The computer adopts the Standard PLC |
Machine 's photo:
Prordct 's sample :
