Help CenterHigh Speed Paper and Plastic Coating Machine,paper Extrusion Coating Machine
Related Products
-
Hydraulic Hole Punching Machine,punching Machine by HydraulicUS$ 1,600 - 1,900MOQ: 1 Set -
High Speed Paper Cutting Machine,roll Paper Cutting MachineNegotiableMOQ: 1 Set
-
High Speed Paper Cutting Machine,roll Paper Slitting MachineNegotiableMOQ: 1 Set
-
High Speed Paper Cutting Machine,roll Paper Slitting Machine,china Paper Cutting MachineNegotiableMOQ: 1 Set
-
High Speed Paper Cutting Machine,china Paper Cutting Machine,slitting LineNegotiableMOQ: 1 Set
Specifications
1, film coating and laminating pe pp hdpe ldpe2. (width 1100mm to1500mm) Extrusion coating laminating
3. laminate on paper
Main technical data
| No. | Character |
specification |
| 1 | Mould |
Diameter 90mm, L/D: 32:1 |
| 2 | Mould material |
38CrMoAl,hardness treatment, surface with Nitride |
| 3 | T-die |
New type featheredge mould |
| 4 | Gear box |
High strength hard tooth surface reduction gear box |
| 5 | Applying materials |
Roll base paper, PET, BOPP and so on |
| 6 | Coating material |
PP, PE |
| 7 | Coating Thickness |
0.012-0.035mm (single layer) |
| 8 | Coating width |
1100-1500mm |
| 9 | Symmetrical degree of coating |
±6% |
| 10 | Max extruding capacity |
180kg/h |
| 11 | Mechanism speed |
0~150m/min |
| 12 | Unwinding systerm |
Double shaft turning and winding without reducing speed |
| 13 | Unwinding tension |
Vector frequency conversion motor |
| 14 | rectifying system |
automatic pneumatic rectifying equipment |
| 15 | Rectifying journey |
±100mm |
| 16 | Deviation rectifying precision |
±0.5mm |
| 17 | Rewinding systerm |
Shaft turning and winging center unwinding |
| 18 | rewinding tension |
vector frequency conversion motor |
| 19 | Unwinding diameter and rewinding diameter |
1200mm |
| 20 | Pneumatic roller for unwinding and winding |
3 inch (diameter: φ73mm |
| 21 | Total power |
About 130kw |
| 22 | Size (L×W×H): |
8500mm×8500mm×3200mm |
| 23 | Total weight |
About 18000 kg |
Key parts brand list
| No. | part |
Brand |
| 1 | Breaker motor | siemens |
| 2 | Inverter motor | ABB |
| 3 | inverter | invance |
| 4 | encoder | omron |
| 5 | Air cylinder | Taiwan |
| 6 | PLC mould | |
| 7 | T-die (steel material) | |
| 8 | Temperature meter | |
| 9 | Tension controller | |
| 10 | Human interface | |
| 11 | contactor | |
| 12 | Air parts | |
| 13 | Lower friction air cylinder |
