hd sdi to hdmi converter 1080p with asb housing mini size sdi converter
Introduction:
The SDI to HDMI Converter converts SDI or HD-SDI to HDMI for driving HDMI monitors.
Embedded SDI/HD-SDI audio is supported in the HDMI output allowing a convenient single cable audio/video connection.
Features:
* No need to install drivers, portable, flexible, plug and play.
* Low power, No power adaptor.
* Auto detect resolution of HD-SDI, SD-SDI and 3G-SDI
* Full HDMI supported with embedded 48KHZ digital audio
* HDMI 1.3 output resolution: 720P@50HZ, 720P@60HZ, 1080i@50HZ, 1080i@60HZ, 1080P@24HZ, 1080P@25HZ, 1080P@30HZ, 1080P@50HZ, 1080P@60HZ
Parameters:
| Product Name | hd sdi to hdmi converter |
Model NO |
PETSH |
Signal Inputs |
SDI Signal (HD-SDI, SD-SDI and 3G-SDI) |
Output Video |
HDMI Signal |
SDI date rate |
270Mb/s, 1.485Gb/s, 2.97Gb/s |
SDI input resolution |
SD 525i, 625i; HD720P@24HZ, 720P@25HZ, 720P@30HZ, 720P@50HZ, 720P@60HZ, HD 1080i@50HZ; 1080i@60HZ; HD 1080P@24HZ, 1080P@25HZ, 1080P@30HZ, 1080P@50HZ,1080P@60HZ Recommended resolution: 720P@50/60HZ, 1080P@50/60HZ
|
Limited Warranty |
1 Year Parts and Labor |
Operating Temperature |
0°C to +50°C |
Operating Humidity |
10% to 85 % RH (no condensation) |
Storage Temperature |
-10°C to +80°C |
Storage Humidity |
5% to 90 % RH (no condensation) |
Power Supply |
USB Cable |
Power consumption (Max) |
5W |
Converter Unit Cert. |
FCC,CE, |
User Manual |
English Version |
Diagram:
Packaging contents:
1) Main unit
2) USB Power Cable.
3) User’s Manual.
Packing:
1. Bubble package, save shipping cost
2) Neutral gift box, beautiful in appearance.
Payment & Shipping
Advantages:
1) We are one member of HDMI Association, export to any country is legal .
2)Specialized in HDMI products manufacture more than 6 years, stronger research and development team
3) 0 Risk for clients.More overseas exhibitions (Hongkong,Americal,Brazil,Germany etc.) are convenient for testing our products
4) Most regular customers from U.S.A , Brazil, Europe countries, Russia, Australia
5) OEM, ODM service avaliable
6) Stronger aftersales (RMA) service as manufacturer.
7) Certs : CE, FCC, RoHS, HDMI Power Adaptor
About us:
Protech Electronic & Technology Limited,brand as Protech is a market leading manufacturer of HDMI products.Our compay was founded in 2008.Over the years,Protech has gained experience and knowledge in electronic business,market development and the HDMI industry.We have always found pride in our solid quality control,exceptional products,immediate availability and continual product development.A keen sense of what disteibutors and their customers need to build and grow
Office & Factory Outlook:
Production Flow :
Pre-Sale: Respond Customer's inquiry in 12 hours, answering all reasonable questions raised, help make sales plans, recommend products for different market, help customer with custom-design packages etc.
On-Sale: after order is placed, we will keep close eyes on the production schedule to make sure the cargo will be delivered in time as promised. and cargo will be inspected for 4 times before delivery.
After-Sale: after the cargo is dispatched, we will help to track the goods and notity customer when cargo arrrived the destination. also, we will keep an eye on the cargo sales status. If the end user came across a problem, we can offer technical support/suggestions, etc.
Warranty: 2 years warranty for long-term business customers.
Back-up: product defect rate is almost 0%, but if a product needs repair, we can help to do that. if the products is unable to repair, we will send new one for replacement.
OEM & ODM:
Certification:
Exhibition we attend:
If you have any question, pls feel free to contact us for more details
QQ: 2628761957
