Specifications
1)3 port HDMI Switch,Mini HDMI Switch 3x12)HDCP Compliant,1080P,with remote control
3)HDMI,RoHS,CE,FCC Cert
4) OEM
mini hdmi 3x1 switcher cost reduce PET0301D
Item: hdmi switch 3 in 1 out ,hdmi switch 3x1, 3 port hdmi switch ,3 input 1 output hdmi switch, hdmi 3x1 switcher , hdmi 3 port switch
Introduction
This is a kind of high performance HDMI Switcher. It can easily switches three sources to one display. It not only has the key-press-switching function, but also has intelligent function. With one fixed HDMI cable (pigtail) this switch not only reduces cost but also save time for consumers.
Features
* Multifunctional on switching, intelligent or mechanical
* Support HDMI1.3b.
* Support highest video resolution 1080p.
* High performance up to 2.5Gbps .
* Support 12bit per channel (36bit all channel) deep color.
* Support uncompressed audio such as LPCM.
* Support compressed audio such as DTS Digital, Dolby Digital (including DTS-HD and Dolby True HD)
* Support 3D
Specifications
| Input DDC Signal | 5 volts p-p (TTL) |
| Maximum Single Link Range | 1920X1080p |
| Output Video | HDMI 1.3b |
| Vertical Frequency Range | 50/60Hz |
| Video Amplifier Bandwidth | 2.5Gbps/250MHz |
| Interlaced(50&60Hz) | 480i,576i,1080i |
| Progressive(50&60Hz) | 480p,576p,720p,1080p |
| Limited Warranty | 1 Year Parts and Labor |
| Operating Temperature | 0°C to +70°C |
| Operating Humidity | 10% to 85 % RH (no condensation) |
| Storage Temperature | -10°C to +80°C |
| Storage Humidity | 5% to 90 % RH (no condensation) |
| External Power Supply | No power needed |
| Power consumption (Max) | 5W |
| Converter Unit | FCC,CE |
| User Manual |
Detail pictures
Package : Neutral gift box,color box or custom design.
Neutral gift box
