HDMI splitter 1 in 8 out hdmi splitter 1x8 by Cat5e/ cat 6 cable UTP support 3D max up to 50m support 1080p for hot video player
1.0 Introduction
This HDMITM 1x8 Splitter Extender allows a single HDMITM device to be broadcast to up to eight remote displays over Cat5e/6 or better LAN cable at distance up to 50m(164ft). It’s an ideal solution to help you create a custom HDMITM distribution and extension for many applications including digital signage and video conferencing. With only one transmitter, it requires a single receiver unit per remote display that you are connecting.
2.0 Features
* One pair as a full functional module, no need of setting
* Use cost-effective LAN cable for long distance transmission
* Follow the standard of IEEE-568B
* Transmission distance can be up to 50m@1080p via Cat6 Cable
* Automatic feedback, equalize and amplifier the HDMI signal according to the cable length
* Support highest video resolution up to 1080p
* Support 165MHz/1.65Gbps per channel (4.95Gbps all channels) bandwidth
* Support 8bit per channel (24bit all channels) deep color
* Support uncompressed 2 channel audio such as LPCM
* Support compressed audio such as DTS, Dolby Digital (including DTS-HD Master AudioTM and Dolby TrueHD)
* Support HDMI (with 3D)
Note: Dolby is a trademark of Dolby Laboratories.
Note: Dolby is a trademark of Dolby Laboratories.
3.0 Specifications
Signal Input |
HDMI Signal |
Input Video Signal |
0.5-1.0volts/p-p |
Output Video |
HDMI Signal |
DTV/HDTV |
480i/576i/480p/576p/720p/1080i/1080p |
Supported Cable Length ( Via Cat6 Cable) |
50m for 1080p |
Video. Amplifier Bandwidth |
1.65Gbps/165MHz |
Vertical Frequency Range |
50/60Hz |
Interlaced Resolutions(50&60Hz) |
480i,576i,1080i |
Progressive Resolutions(50&60Hz) |
480p,576p,720p,1080p |
Limited Warranty |
1 Year Parts and Labor |
Operating Temperature |
0℃ to 70℃ |
Operating Humidity |
10% to 85% RH (no condensation) |
Storage Temperature |
-10℃ to +80℃ |
Storage Humidity |
5% to 90% RH (no condensation) |
Power Supply |
12V DC @Sender, 5V DC @Receiver |
Power Consumption(MAX) |
16W |
Extender Unit Cert |
FCC,CE, RoHS |
Power Supply Cert |
CE,FCC, RoHS |
AC Power Adapter |
US,UK,EU, AUS Standard etc |
User Manual |
English Version |
Note:
1. Ethernet cable quality affects the product performance.
2. Specification is subject to change without prior notice.
3. It might be no display when the product connected to some TVs, due to the hot plug issue.
Please unplug and re-plug in the HDMI Cable, it will resume work.
4. Please disassemble the foot pads when mounting the product on the wall.
4.0 Package & Shipping Contents
1) Main Unit NO.1 Sender x1
2) Main Unit NO.2 Receiver x8
3) 12VDC@3A Power Supply x1
4) 5VDC Power Supply x8
5) Mounting Ears x18
6) User Manual x1
