Wholesale 60m HDMI Network Extender Over Single Cable with IR cat5e/6 Ethernet Cable 3D&1080P Supported Compatible HDCP
1.0 Introduction
The HDMITM Extender lets you extend HDMITM audio/video signal by up to 60 meters (196 feet) over single CAT6 cable. The extender kit includes both the local transmitter and remote receiver units, perfect for point-to-point digital signage applications that require high quality HDMITM video. It also works to extend Infrared IR signals from remote controls, ideal for controlling your video source from your video destination. For perfect performance, the extender comes with a reset function on the receiver, which enables user to adjust the signal to best match the cable length.
2.0 Features
* HDMI over single CAT6 cable transmission up to 60m/196ft
* Supports lossless uncompressed A/V signal transmission
* Signal auto adjustment to match the cable length after press ‘RESET’ button on receiver
* Full HD 1080P transmission to make video image more vivid
* IR signal transmission for easy controlling the source device
* Supports 3D video format
Note: there are 2 RESET on this extender kit, one on ‘Sender’, one on ‘Receiver’.
RESET at Sender: function as restart
RESET at Receiver: function as equalizer
3.0 Specifications
Signal Input |
HDMI Signal |
Input Video Signal |
0.5-1.0volts/p-p |
Output Video |
HDMI Signal |
DTV/HDTV |
480i/480p/576i/576p/720p/1080i/1080p |
CAT-6 Cable |
60m@1080p |
Vertical Frequency Range |
50/60Hz |
Interlaced Resolutions(50&60Hz) |
480i,576i,1080i |
Progressive Resolutions(50&60Hz) |
480p,576p,720p,1080p |
Limited Warranty |
1Year Parts and Labor |
Operating Temperature |
0℃ to 70℃ |
Operating Humidity |
10% to 85% RH (no condensation) |
Storage Temperature |
-10℃ to +80℃ |
Storage Humidity |
5% to 90% RH (no condensation) |
Power Supply |
5V DC |
Power Consumption(Max) |
5W |
Extender Unit Cert |
FCC,CE, RoHS |
Power Supply Cert |
CE,FCC, RoHS |
Power Adapter Standard |
US,UK, EU, AUS standard etc |
User Manual |
English Version |
Note:
1. Ethernet cable quality affects product performance.
2. The specification is subject to change without prior notice.
4.0 Package & Shipping Contents
1) Main Unit NO.1 Sender x 1
2) Main Unit NO.2 Receiver x 1
3) 1 x IR TX Cable
4) 1 x IR RX Cable
5) 5V DC Power Supply x 2
6) Mounting Ears x 4
7) User Manual
5.0 Panel Description
6.0 Connection and Operation
7.0 Company Imformation
About us :
As a specialized independent supplier of HDMI products, Protech Electronics & Technology Limited focuses on high quality image process technology and application design, owns perfect production lines and innovates on technical route continually to provide the best solutions for home media, especially for HD source connection, such as HDMI cable, switcher, splitter, matrix converter and extender.
In addition, Protech provides the prime quality & reasonable price for all our customers, and supports clients with high technology product development, experienced OEM, ODM production and highly effective global logistics. "To serve customers with good quality & price of the world competition" is our winning policy.
Office & Factory Outlook:
Flow of Production :
OEM & ODM:
Certification:
Exhibition:
Pre-Sale: Respond Customer's inquiry in 12 hours, answering all reasonable questions raised, help make sales plans, recommend products for different market, help customer with custom-design packages etc.
On-Sale: after order is placed, we will keep close eyes on the production schedule to make sure the cargo will be delivered in time as promised. and cargo will be inspected for 4 times before delivery.
After-Sale: after the cargo is dispatched, we will help to track the goods and notity customer when cargo arrrived the destination. also, we will keep an eye on the cargo sales status. If the end user came across a problem, we can offer technical support/suggestions, etc.
Warranty: 2 years warranty for long-term business customers.
Back-up: product defect rate is almost 0%, but if a product needs repair, we can help to do that. if the products is unable to repair, we will send new one for replacement.
1.Q:Are you a factory or trading company?
A:We are a Professtional Manufacturer of HDMI Accessories for many years.
2.Q:Where is your factory located? How can I visit there?
A:Our factory is located in NO.6 Baofu Road, Shangmu Gubaolai Industrial Park, Ping Hu Town, Long Gang District,Shenzhen Guangdong, China , are warmly welcome to visit us!
3.Q:What is the material of your Product?
A:The material is ABS. We can also choose material as customers’ requirement.
4.Q:How can I get some samples?
A: We are honored to offer you samples.
5.Q:How does your factory do regarding quality control?
A:Quality is priority. Protech people always attach great importance to quality controlling from the very beginning to the very end.
