Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Products Status:
Stock
Size:
Other, 2.5'', 3.5''
Case Material:
Aluminum
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Netapp Data Storage FAS3220 With Expanded I/ONegotiableMOQ: 1 Piece -
Netapp Data Storage FAS3270 With Expanded I/ONegotiableMOQ: 1 Piece
-
FAS3250 Netapp Data StorageNegotiableMOQ: 1 Piece
-
FAS3220 Netapp Data StorageNegotiableMOQ: 1 Piece
-
Netapp Data Storage FAS3240 With Expanded I/ONegotiableMOQ: 1 Piece
Products Status
Stock
Size
Other, 2.5'', 3.5''
Case Material
Aluminum
External Interface
Other, SAS, FC
Internal Interface
Other, SAS, FC
Brand Name
NetApp
Model Number
FAS2554
Place of Origin
Singapore
Company Information
1. Integrator of HP.
2. Partner of Dell and NetApp.
3. Agent of IBM, EMC, Juniper and Qlogic.
4. Professional on handling and customizing projects and IT solutions.
5. Spirit of keeping long-term business relationship.
NetApp FAS2500 Series FAS2554
Technical specifications
| FAS2554 | FAS2552 | FAS2520 | ||||
| Single Controller | Dual Controller | Single Controller | Dual Controller | Single Controller | Dual Controller | |
| Max. Raw Capacity | 864TB | 864TB | 763TB | 763TB | 504TB | 504TB |
| Internal Drives | 24 | 24 | 24 | 24 | 12 | 12 |
| Supported Internal Drives | ||||||
| Performance HDD | N/A | 600GB, 900GB, 1.2TB | 600GB, 900GB, 1.2 TB | |||
| Capacity HDD | 2TB, 3TB, 4TB,6TB | N/A | 2TB, 3TB, 4TB,6TB | |||
| SSD | 200GB, 400GB, 800GB | 200GB, 400GB, 800GB, 1.6TB | 200GB, 400GB, 800GB, 1.6TB | |||
| Self-encrypting Drives | 4TB at 7.2K RPM AES-256, FIPS 140-2 compliant | 900GB at 10K RPM, 800GB SSD AES-256, FIPS 140-2 compliant | 900GB at 10KRPM, 4TB at 7.2K RPM AES-256, FIPS 140-2 compliant | |||
| Max. Drives (Internal + External) | 144 | 144 | 144 | 144 | 84 | 84 |
| ECC Memory | 18GB | 36GB | 18GB | 36GB | 18GB | 36GB |
| Controller Form Factor | 1 or 2 controllers in a single 4U chassis | 1 or 2 controllers in a single 2U chassis | 1 or 2 controllers in a single 2U chassis | |||
| Maximum Flash Pool | 16TB[1] | 16TB[1] | 16TB[1] | 16TB[1] | 16TB[1] | 16TB[1] |
| NVMEM/NVRAM | 2GB | 4GB | 2GB | 4GB | 2GB | 4GB |
| Onboard I/O: UTA 2 (8Gb FC/16Gb FC/FCoE/10GbE/1GbE[2]) | 4[3] | 8[3] | 4[3] | 8[3] | N/A | N/A |
| Onboard I/O: | N/A | N/A | N/A | N/A | 4[4] | 8[4] |
| 10G Base-T | ||||||
| Onboard I/O: 6Gb SAS | 2 | 4 | 2 | 4 | 2 | 4 |
| Onboard I/O: GbE | 2 | 4 | 2 | 4 | 2 | 4 |
| Notes | ||||||
| [1]16TB for Data ONTAP 8.3, 4TB for Data ONTAP 8.2 (cluster mode and 7-mode). | ||||||
| [2]1GbE optical and copper SFP support starts with the release of Data ONTAP 8.3.1RC | ||||||
| [3]FAS2552 and FAS2554 onboard UTA2 ports can be configured as either 8Gb/16Gb FC port pair or 10GbE/1GbE port pair and mixed combinations. | ||||||
| [4]FAS2520 onboard ports are 10GBASE-T only that can autorange to 1GbE. | ||||||
| Specifications for Scale-Out Configurations (Hybrid and Disk-Only Configurations) | ||||||
| FAS2554 | FAS2552 | FAS2520 | ||||
| NAS/SAN Scale-out | 1 nodes (4 HA pairs) | 1 nodes (2 HA pairs) | ||||
| Maximum Drives | 576 | 576 | 168 | |||
| Maximum Raw Capacity | 3.5PB | 3.0PB | 1PB | |||
| Maximum Flash Pool | 64TB | 64TB | 32TB | |||
| Maximum Memory | 144GB | 144GB | 72GB | |||
| Cluster Interconnect | 10GbE | 10G Base-T | ||||
| FAS2554 | FAS2552 | FAS2520 | ||||
| Storage Protocols Supported | FAS2552 / FAS2554 = FC; FCoE; iSCSI; NFS; pNFS; CIFS/SMB | |||||
| FAS2520 = iSCSI; NFS; pNFS; CIFS/SMB | ||||||
| OS Version | Data ONTAP 8.2.2 or later | |||||
| High-Availability Features | Alternate Control Path (ACP); thernet-based service processor and Data ONTAP management interface; redundant hot-swappable controllers, cooling fans, and power supplies | |||||
| Supported Configurations | Cluster Configurations | |||||
| Single-node cluster | ||||||
| Two-node switchless cluster | ||||||
| Two-node switched cluster | ||||||
| Clusters of HA pairs | ||||||
| 7-Mode Configurations | ||||||
| Controllers:Single controller; active-active controllers in an HA pair; active-passive controllers in an HA pair | ||||||
| Back-End Disks:Single path with single controller or HA pair; dual path with single controller MP-HA with HA pair (best practice) | ||||||
| Disk Shelves Supported | DS2246 (2U; 24 drives, 2.5" SFF) | |||||
| DS4246 (4U; 24 drives, 3.5" LFF) | ||||||
| For complete details on expansion disk shelves and supported media in those shelves, refer to theNetApp Disk Shelves and Storage Mediaweb page. | ||||||
| Maximum RAID Group Sizes | RAID 6 (RAID-DP) | |||||
| SAS, SSD, and FC: 28 (26 data disks plus 2 parity disks) | ||||||
| SATA: 20 (18 data disks plus 2 parity disks) | ||||||
| RAID 4 | ||||||
| SAS, SSD, and FC: 14 (13 data disks plus 1 parity disk) | ||||||
| SATA: 7 (6 data disks plus 1 parity disk) | ||||||
| RAID 6 + RAID 1 or RAID 4 + RAID 1 (SyncMirror) | ||||||
| Host/Client Operating Systems Supported | Windows 2000, Windows Server 2003, Windows Server 2008, Windows Server 2012, Windows XP, Linux, Oracle Solaris, AIX, HP-UX, Mac OS, VMware, ESX | |||||
| Max. Number of LUNs | 2048 per controller | |||||
| Number of Supported Hosts | Up to 6 ports per controller configured as front-end (host) connectivity ports | |||||
| Up to 12 directly connected servers per active-active configuration | ||||||
| Connected hosts per HA pair: Up to 512 SAN connected servers | ||||||
| FlexVol Volumes | Up to 1,000 per controller | |||||
| Snapshot Copies | Up to 255,000 per controller | |||||
| Maximum Volume Size | 60TB | |||||
| Maximum Aggregate Size | 120TB | |||||
| System Environmental Specifications | ||||||
| FAS2554 | FAS2552 | FAS2520 | ||||
| Thermal Rating | 1,948 BTU (typical) | 1,218 BTU (typical) | 1,164 BTU (typical) | |||
| 2,044 BTU (worst case) | 1,737 BTU (worst case) | 1,843 BTU (worst case) | ||||
| Weight[1] | 111.3 lbs | 55.4 lbs | 58.6 lbs | |||
| Height | 7" (17.9 cm), fits into 4U space | 3.35" (8.5 cm), fits into 2U space | 3.45" (8.76 cm), fits into 2U space | |||
| Width | 19" IEC rack-compliant (17.6", 44.7 cm) | |||||
| Depth (without cable management brackets) | 22" (56 cm) | 19" (48 cm) | 20" (50.8 cm) | |||
| Operating Temperature, Altitude, and Relative Humidity | 50F to 104F (10C to 40C); at 3,000m (at 10,000') elevation; 20% to 80% relative humidity, noncondensing | |||||
| Nonoperating Temperature and Relative Humidity | 40F to 158F -40C to 70C; at 12,192m at E40,000' typical of unconditioned airplane cargo bay, 8% to 80% relative humidity, noncondensing, in original container | |||||
| Operating Acoustic Noise | FAS2520: | |||||
| Declared sound power (LwAd) per ISO 9296: 6.2 Bel | ||||||
| Sound pressure (LpAm) (bystander positions): 49.6 dB | ||||||
| FAS2552: | ||||||
| Declared sound power (LwAd) per ISO 9296: 6.2 Bel | ||||||
| Sound pressure (LpAm) (bystander positions): 49.6 dB | ||||||
| FAS2554: | ||||||
| Declared sound power (LwAd) per ISO 9296: 6.1 Bel | ||||||
| Sound pressure (LpAm) (bystander positions): 49.6 dB | ||||||
| Compliance | RoHS-compliant(PDF) | |||||
| Safety/Emissions/Immunity | Safety:EN 60950, CE, CSA 60950, UL 60950, CB IEC60950-1 (all national deviations), EN60825-1, IRAM, CU, BIS, BSMI, SONCAP, NRCS LOA (South Africa) | |||||
| Emissions/Immunity:FCC Part 15 Class A, ICES-03, CE, KCC, VCCI, AS/NZS CISPR 22, EN55022, EN55024, EN61000-3-2, EN61000-3-3, SABS COC (South Africa), BSMI | ||||||
Picture Showcase
We take product photos freshly in warehouse.
Our Services
1. Reply within 3-5min, solving further questions within 12h. 7x12h online service.
2. 1-3yr warranty for different items. Supplying new replacement within 3 days after we receive the damaged item, 7x8h service.
3. Online normal technical support and service 7x12h, troubleshooting 5x9h Tec. Sup&Svi.
