Home > Computer Products > Network Hardware & Parts > Network Switch > WS-C3650-48PD-E Catalyst 3650 48 Port PoE 2X10G Uplink Ip Services

WS-C3650-48PD-E Catalyst 3650 48 Port PoE 2X10G Uplink Ip Services

WS-C3650-48PD-E Catalyst 3650 48 Port PoE 2X10G Uplink Ip Services thumbnail-1
WS-C3650-48PD-E Catalyst 3650 48 Port PoE 2X10G Uplink Ip Services thumbnail-2
WS-C3650-48PD-E Catalyst 3650 48 Port PoE 2X10G Uplink Ip Services photo-1
WS-C3650-48PD-E Catalyst 3650 48 Port PoE 2X10G Uplink Ip Services photo-2
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Products Status:
Stock
Ports:
Other, ≥ 48
Transmission Rate:
10/100/1000Mbps
Contact Supplier Request Quote Chat Now
Shenzhen Hisco Technology Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Products Status Stock
Ports Other, ≥ 48
Transmission Rate 10/100/1000Mbps
Function POE, QoS, SNMP
Communication Mode Other, Full-Duplex & Half-Duplex
Certification UL, CE
Switch Capacity 176Gbps
Brand Name For cisco
Model Number WS-C3650-48PD-E
Place of Origin Beijing, China
Company Information

1. Integrator of HP.

2. Partner of Dell and NetApp.

3. Agent of IBM, EMC, Juniper and Qlogic.

4. Professional on handling and customizing projects and IT solutions.

5. Spirit of keeping long-term business relationship.

Product Description

WS-C3650-48PD-E Catalyst 3650 48 Port PoE 2X10G Uplink Ip Services



Device Type Switch - 48 ports - Managed - stackable
Enclosure Type Desktop, rack-mountable 1U
Subtype Gigabit Ethernet
Ports 48 x 10/100/1000 poe + 2x 10G SFP
Power Over Ethernet (PoE) PoE+
PoE Budget 775 W
Performance Switching capacity : 176 Gbps
Forwarding performance : 130.95 Mpps
Capacity IPv4 routes : 24000
Virtual interfaces (VLANs) : 255
Switched virtual interfaces (SVIs) : 1000
MAC Address Table Size 32000 entries
Jumbo Frame Support 9198 bytes
Routing Protocol Static IP routing
Remote Management Protocol SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, SSH, CLI
Features Full duplex capability, Layer 2 switching, DHCP support, auto-negotiation, ARP support, trunking, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, Syslog support, IPv6 support, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, DHCP snooping, Dynamic Trunking Protocol (DTP) support, Port Aggregation Protocol (PAgP) support, Trivial File Transfer Protocol (TFTP) support, Access Control List (ACL) support, Quality of Service (QoS), RADIUS support, MLD snooping, Dynamic ARP Inspection (DAI), Unicast Reverse Path Forwarding (URPF), Uni-Directional Link Detection (UDLD), Rapid Per-VLAN Spanning Tree Plus (PVRST+), Shaped Round Robin (SRR), LLDP support, Link Aggregation Control Protocol (LACP), MAC Address Notification, Remote Switch Port Analyzer (RSPAN), Hot Standby Router Protocol (HSRP) support, Energy Efficient Ethernet, Strict Priority Queuing (SPQ), Class of Service (CoS), DiffServ Code Point (DSCP) support
Compliant Standards IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3at
Power AC 120/230 V ( 50/60 Hz )
Power Redundancy Optional
Dimensions (WxDxH) 44.5 cm x 48.6 cm x 4.4 cm
Weight 10 kg



More Catalyst 3650 Switch Models:



WS-C3650-48FS-L Catalyst 3650 48 Port Full PoE 4x1G Uplink LAN Base
WS-C3650-24PS-S Catalyst 3650 24 Port PoE 4x1G Uplink IP Base
WS-C3650-48FS-E Catalyst 3650 48 Port Full PoE 4x1G Uplink IP Services
WS-C3650-48TS-E Catalyst 3650 48 Port Data 4x1G Uplink IP Services
WS-C3650-48PS-E Catalyst 3650 48 Port PoE 4x1G Uplink IP Services
WS-C3650-24PS-E Catalyst 3650 24 Port PoE 4x1G Uplink IP Services
WS-C3650-24TS-E Catalyst 3650 24 Port Data 4x1G Uplink IP Services
WS-C3650-48TS-S Catalyst 3650 48 Port Data 4x1G Uplink IP Base
WS-C3650-48FS-S Catalyst 3650 48 Port Full PoE 4x1G Uplink IP Base
WS-C3650-48PS-L Catalyst 3650 48 Port PoE 4x1G Uplink LAN Base
WS-C3650-24PS-L Catalyst 3650 24 Port PoE 4x1G Uplink LAN Base
WS-C3650-48TS-L Catalyst 3650 48 Port Data 4x1G Uplink LAN Base
WS-C3650-24TS-L Catalyst 3650 24 Port Data 4x1G Uplink LAN Base
WS-C3650-48PS-S Catalyst 3650 48 Port PoE 4x1G Uplink IP Base
WS-C3650-24TS-S Catalyst 3650 24 Port Data 4x1G Uplink IP Base
Picture Showcase

We take product photos freshly in warehouse.WS-C3650-48PD-E Catalyst 3650 48 Port PoE 2X10G Uplink Ip Services



WS-C3650-48PD-E Catalyst 3650 48 Port PoE 2X10G Uplink Ip Services

Our Services

1. Reply within 3-5min, solving further questions within 12h. 7x12h online service.

2. 1-3yr warranty for different items. Supplying new replacement within 3 days after we receive the damaged item, 7x8h service.

3. Online normal technical support and service 7x12h,  troubleshooting 5x9h Tec. Sup&Svi.

Packaging & Shipping

WS-C3650-48PD-E Catalyst 3650 48 Port PoE 2X10G Uplink Ip Services
