LED PCB 94V0
MCPCB for high power LED 3*1W candle light
Advantage
1.MOQ:10pcs
2.sample lead time:1days
3.Aluminum board
4.LED specified
5.1200pcs in stock
specification:
| Item | 3*1W |
| Layer | Single sided |
| Surface Finishing | HASL |
| Molding | Die cast |
| color of Soldermask | black |
| solder resist oil | black Photoimagable Resist oil |
| Diameter (mm)/size: | 23mm |
| Thickness (mm) | 1.0mm |
| Base Material | Aluminum Alloy |
| Copper Thickness: | 1oz |
Important:
The speicificaiton of MCPCB we can make as below:
Thickness of Board:0.6mm/ 0.8mm/ 1.0mm/ 1.2mm/ 1.6mm/ 2.0mm/ 2.5mm ,
Surface treatment: Heat Air leveling(HAL)/ Entek(OSP)/ Immersion Gold Plating
color of Solder Mask: Green/white/ black/
color of words in PCB: Green/ white/ Black
Copper thickness:0.5oz/1oz/2oz/3oz
Min. Trace width:0.1mm
Min. line spacing:0.1mm
Min. Hole dia. :1.0mm
Advanced:
We can make the PCB board According your design,Pls send us your drawing for exact price!
TRADE TERMS:
- Customer design Sample lead-time: 5days; order size less than 30m² lead time: 7days after sample confirmed
- Payment: 30%T/T deposit, the balance paid against the B/L Fax Copy or 100% L/C at sight;
- Shipping: By Express (EMS,DHL, UPS etc), by air or by sea;
- Logo: According to your requirements;
Others with our confirmations.
Below are common PCB in stock
