Professional Manufacturer Ceramic Pcb,asic Miner Pcb Board,double Sided Pcb

Name: Professional Manufacturer Ceramic Pcb,asic Miner Pcb Board,double Sided Pcb
Brand: LEAD
Availability: InStock

FOB Price

US$ 0.99 - 9.99 / Square Meter

10 Square Meters(Min. Order)

Port Shenzhen
Payment TermsMoney Gram Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China	Brand Name	LEAD
Model Number	ceramic pcb	Base Material	Aluminum Base
Copper Thickness	0.5oz-6oz	Board Thickness	0.6-3.0mm
Min. Hole Size	0.2mm	Min. Line Width	0.10mm
Min. Line Spacing	0.08mm	Surface Finishing	HAL/OSP/Immersion Gold Plating/Gold Plating/Sn Plating/Immersion Sn

Product Description

Professional manufacturer ceramic pcb,asic miner pcb board,double sided pcb

Company Information

LEAD INDUSTRY LIMITED is an expert at PCB&PCBA, high power led,COB LED, SMD LED, SMT service manufacture, based in Shenzhen, Guangdong, China.

LEAD INDUSTRY LIMITED was founded in 2003,has two factory located in Shenzhen and Huizhou. We mainly offer Circuit Board manufacturing and OEM PCB Assembly Service, also with LED, all our product with CE&ROHS,UL: E333645, From our ISO9001 certified factory, we turn out up to 80000 square meter of PCBs monthly.

LEAD INDUSTRY LIMITED has a strong factory strength, supplier for GE,ABB,TCL,IKEA ect, which building a about 540000m2 industrial park in Jiangxi china.

Specification:

Item		Specification	Remark
Layer		1-16 Layers
Material		FR-4, Aluminum, Ceramic based, Ployurethane/Mylar
Board Thickness		0.04mm-3.2mm	Single FPC: 0.04mm (2mil)
Mini. Core Thickness		0.1mm (4mil)
Copper Thickness		Min. 1/2 oz, Max 4 oz
Min. Trace/ Spacing Width		0.075mm (3mil)
Min. Hole for CNC Drilling		0.25mm (10mil)	Laser Drilling: 0.1mm(4mil)
Min. Hole for Punching		0.7mm (28mil)
Dimension Tolerance	Hole Position	±0.075mm (3mil)
	Trace Width	±0.05mm (2mil)
	Hole Size	PTH±0.15mm (6mil) NPTH±0.05mm (2mil)
	Outline	Routing±0.15mm (6mil) Punching±0.10mm (4mil)
	Bow and Twist	0.7% —1.0%
Surface Finishing		Nickel/Gold Plating/ENIG/HAL
Insulation Resistance		10KΩ - 20MΩ
Conductivity		<50Ω
Test Voltage		300V
V-Cut	Panel Size	Min.110mm × 100mm, Max 660mm ×600mm
	Board Thickness	Min.0.6mm (24mil)
	Temain Thickness	Min.0.3mm (12mil)
	Tolerance	±0.1mm (4mil)
	Groove Width	Max.0.5mm (20mil)
	Groove to Groove	Min.10mm
	Groove to Trace	Min.0.50mm (20mil)
Slot	Slot Size Tol ≥2W	PTHL: ±0.15mm (6mil) W: ±0.1mm (4mil)
Slot	Slot Size Tol ≥2W	NPTHL: ±0.125mm (5mil) W: ±0.1mm (4mil)
Mini. Spaing between hole edge to circuitry pattern		PTH Hole: 00.13mm (5mil)
Mini. Spaing between hole edge to circuitry pattern		NPTH Hole: 0.18mm (7mil)
Registration Tolerance of Front/Back image	Font image vs back image	0.075mm (3mil)
Registration Tolerance of Front/Back image	Font image vs back image	0.075mm (3mil)
Multilayer	Layer-Layer misregistration	Max.4layers: 0.15mm (6mil)
	Layer-Layer misregistration	Max.6-16layers: 0.025mm (10mil)
	Min. spacing between hole edge to circuitry pattern of an inner layer	0.25mm (10mil)
	Min. Spacing between board outline to circuitry pattern of an inner layer	0.25mm (10mil)
	Board thickness tolerance	4layers: ±0.13mm (5mil)
	Board thickness tolerance	6-16lyaers: ±0.15mm (6mil)
	Impedance Control	60ohm ±10%

Product Description

Packaging & Shipping

Packiging:

Our Services

We are leadgroup, shenzhen manufactuer for high power LED(Epistar, Bridgelux), COB LED,SMD LED(2835,5630,3014,3535 ect Samsung/Epistar/LG/CREE),PCB(AL PCB,FR4, FPC,CEM-1,CEM-3 ect.)&PCBA, SMT assembly, pcb&pcba engineering design since 2003, all our products with UL,CE&ROHS,ect. Our client including GE,ABB,FSL,IEKA,Beghelli, ect.

we can do pcb/ do SMT for you, also design for you, do LED/buy led,supply,lens for you

Ablout LEADGROUP

Factory view

FAQ

Q:Can you offer samples before mass production?

A: Yes, we can custom you sample to test before mass production

Q: When will I get the quotation after sent Gerber, BOM and test procedure?
A: Within 6 hours for PCB quotation and around 24 hours for PCBA quotation.

Q: How can I know the process of my production?
A: 7-10 days for PCB production and components purchasing, and 10 days for PCB assembly and

Testing

Q: How can I make sure the quality of my PCBAs?
A: We ensure that each piece of PCBA products work well before shipping. We'll test all of them according to your test procedure
