High stability temperature cycle pcb, Ceramic printed circuit board in Shenzhen
- 5000 Square Meter / Square Meters per Month
- Shenzhen
- Credit Card
Product Details
Place of Origin: | Guangdong, China | Brand Name: | LEAD | Model Number: | ceramic pcb |
Base Material: | Aluminum Base | Copper Thickness: | 0.5oz-6oz | Board Thickness: | 0.6-3.0mm |
Min. Hole Size: | 0.2mm | Min. Line Width: | 0.10mm | Min. Line Spacing: | 0.08mm |
Surface Finishing: | HAL/OSP/Immersion Gold Plating/Gold Plating/Sn Plating/Immersion Sn |
Product Description
High stability temperature cycle pcb, Ceramic printed circuit board in Shenzhen
Company Information
LEAD INDUSTRY LIMITED is an expert at PCB&PCBA, high power led,COB LED, SMD LED, SMT service manufacture, based in Shenzhen, Guangdong, China.
LEAD INDUSTRY LIMITED was founded in 2003,has two factory located in Shenzhen and Huizhou. We mainly offer Circuit Board manufacturing and OEM PCB Assembly Service, also with LED, all our product with CE&ROHS,UL: E333645, From our ISO9001 certified factory, we turn out up to 80000 square meter of PCBs monthly.
LEAD INDUSTRY LIMITED has a strong factory strength, supplier for GE,ABB,TCL,IKEA ect, which building a about 540000m2 industrial park in Jiangxi china.
Specification:
Item | Specification | Remark | |
Layer | 1-16 Layers | ||
Material | FR-4, Aluminum, Ceramic based, Ployurethane/Mylar | ||
Board Thickness | 0.04mm-3.2mm | Single FPC: 0.04mm (2mil) | |
Mini. Core Thickness | 0.1mm (4mil) | ||
Copper Thickness | Min. 1/2 oz, Max 4 oz | ||
Min. Trace/ Spacing Width | 0.075mm (3mil) | ||
Min. Hole for CNC Drilling | 0.25mm (10mil) | Laser Drilling: 0.1mm(4mil) | |
Min. Hole for Punching | 0.7mm (28mil) | ||
Dimension Tolerance | Hole Position | ±0.075mm (3mil) | |
Trace Width | ±0.05mm (2mil) | ||
Hole Size | PTH±0.15mm (6mil) NPTH±0.05mm (2mil) | ||
Outline | Routing±0.15mm (6mil) Punching±0.10mm (4mil) | ||
Bow and Twist | 0.7% —1.0% | ||
Surface Finishing | Nickel/Gold Plating/ENIG/HAL | ||
Insulation Resistance | 10KΩ - 20MΩ | ||
Conductivity | <50Ω | ||
Test Voltage | 300V | ||
V-Cut | Panel Size | Min.110mm × 100mm, Max 660mm ×600mm | |
Board Thickness | Min.0.6mm (24mil) | ||
Temain Thickness | Min.0.3mm (12mil) | ||
Tolerance | ±0.1mm (4mil) | ||
Groove Width | Max.0.5mm (20mil) | ||
Groove to Groove | Min.10mm | ||
Groove to Trace | Min.0.50mm (20mil) | ||
Slot | Slot Size Tol ≥2W | PTHL: ±0.15mm (6mil) W: ±0.1mm (4mil) | |
NPTHL: ±0.125mm (5mil) W: ±0.1mm (4mil) | |||
Mini. Spaing between hole edge to circuitry pattern | PTH Hole: 00.13mm (5mil) | ||
NPTH Hole: 0.18mm (7mil) | |||
Registration Tolerance of Front/Back image | Font image vs back image | 0.075mm (3mil) | |
Multilayer | Layer-Layer misregistration | Max.4layers: 0.15mm (6mil) | |
Max.6-16layers: 0.025mm (10mil) | |||
Min. spacing between hole edge to circuitry pattern of an inner layer | 0.25mm (10mil) | ||
Min. Spacing between board outline to circuitry pattern of an inner layer | 0.25mm (10mil) | ||
Board thickness tolerance | 4layers: ±0.13mm (5mil) | ||
6-16lyaers: ±0.15mm (6mil) | |||
Impedance Control | 60ohm ±10% |
Packiging:
We are leadgroup, shenzhen manufactuer for high power LED(Epistar, Bridgelux), COB LED,SMD LED(2835,5630,3014,3535 ect Samsung/Epistar/LG/CREE),PCB(AL PCB,FR4, FPC,CEM-1,CEM-3 ect.)&PCBA, SMT assembly, pcb&pcba engineering design since 2003, all our products with UL,CE&ROHS,ect. Our client including GE,ABB,FSL,IEKA,Beghelli, ect.
