Home > Products > New Products > router cnc with high quality TJ-1530
router cnc with high quality TJ-1530
- QINGDAO
- T/T Credit Card
You May Like
Product Details
| Condition | New | CNC or Not | CNC | |
| Place of Origin | Shandong, China | Brand Name | tianjiao | |
| Model Number | TJ-1530 | Voltage | AC380V 50Hz | |
| Power(W) | 8.87KW | Dimension(L*W*H) | 1500X3000x400mm | |
| Weight | 500kg | Certification | CE/FDA | |
| Warranty | 1 year | After-sales Service Provided | Overseas third-party support available |
Product Description
Specifications
router cnc with high quality TJ-1530high speed, run steady, high precision, Whole Steel structure, imported square orbit
router cnc with high quality TJ-1530
high speed, run steady, high precision, Whole Steel structure, imported square orbit
router cnc with high quality ,This type machine equipped with top fittings.
1. China domestic no oil vacuum pump, also can equipped with different vacuum pumps according to customers requirements.
2.The Spindle equipped is 4..5KW China domestic made water cooling spindle. It is fit for engraving and cutting on MDF, solid wood material and other hard wood.
3. oiling system
4. New style DSP control system.
5.Top rank international vacuum adsorb table surface, it is made from electric wood board with high adsorb, can adsorb different materials, this material with big density(1.3-1.45g/cm), heat resisting, it can resist high temperature (115 c.)
6.High speed, high efficient, max speed can reach to above 35meters/min, it can reach to 25 meters/min when processing wave board, it can match 4-5 common type machines.
router cnc with high quality
NO. Description | Parameter | |
1 | X.Y working area | 1500X3000mm |
2 | Z working area | 200mm |
3 | Table | 1680X3500mm |
4 | Max speed | 35m/min |
5 | Working Speed | 25m/min |
6 | Resolution/ work delicacy | 0.02mm |
7 | Repositioning Accuracy | 0.05mm |
8 | Interface | USB |
9 | Command | G code*.u00*.mmg* plt |
10 | Surroundings for software | windows98/2000/xp |
11 | Control system | DSP control system |
12 | Power(spindle power is not included) | 8.87KW |
13 | Working voltage | AC380V 50Hz |
14 | Spindle power (domestic made) | 4.5KW water cooling spindle |
15 | Spindle rotating speed | 0-24000rpm/min |
16 | Motor | Stepper |
Contact Us
- Jinan Tian Jiao Machinery Manufacture Co., Ltd.
- Contact nameTian Jiao Chat Now
- Phone86-531-88038806
- AddressNo. 8, Yuhua Road, Fujia Industrial Park, Licheng District
