Mini CNC Router - 2.2KW Water Cooled

Specifications

Mini CNC Router - 2.2KW Water Cooled
1.CE certificate
2.1.5kw water cooling spindle
3.DSP control system





Mini CNC Router - 2.2KW Water Cooled

















Application

1.Woodworking industry: classic red wood furniture processing.

2.Advertising industry: advertising billboards, signs making, acrylic cutting, plastic moulds making, other advertising materials making.

3.other industry: all kinds photo engraving, 3d working, widely used in crafts and gifts making also.

4.can be used: double-color board, acylic, rubber plate, wooden board, organic glass, lotus board, PVC pipe.



Configuration

Vertical support, cast iron bed body, round orbits, ballscrew, DSP control system, 1.5KW Chinese water cooling spindle, UCANCAM software and Type3 software.



Features

1.Adopt Germanic double nut ballscrew and imported orbit.

2.Break point memory mode to make sure continuous working after electronic drop or other postpone situation.

3.Special saving mode of different pints

4.Gantry mode movement is more durable and will not distorte after long time use and the reposition precision is much better.

5.The desktop type structure offers more stable and more smooth work.

6.Widely used for architectural model, schools, companies and governments.



Parameters

NO.   Description		Parameter
1	X,Y Working area	600×900mm
2	Z Working area	80mm
3	Max. speed	6m/min
4	Max working speed	3m/min
5	Working delicacy	0.05mm
6	Repositioning Accuracy	0.03mm
7	Max. feeding Height	75mm
8	Command	G code*.U00*.mmg*.plt
9	Surroundings for software	windows98/2000/xp
10	Power (spindle is not included)	300W
11	Working voltage	AC220V 50Hz
12	Spindle power	1.5KW water cooling spindle
13	Spindle rotating speed	0-24000rpm/min
14	Drive motor	Stepper
