multi head 4 axis cnc drilling tools machine
- 200 Set / Sets per Month
- qingdao
- T/T Credit Card
You May Like
-
multi head 4 axis cnc milling machine
-
4 axis 3D wood cnc router caring making buddha machine
-
hot sale 4 axis swing head cnc router machine to make figure,sculpture,mould
-
2015 HOT SALE HSD9kw 180 degree rotary syntec control 4 axis cnc router
-
4 axis 180 degree swing rotary 9kw HSD spindle cnc router servo motor
-
CE!!!! china rotary cnc router 4axis 8heads/wood working cylinder engraving 4axis cnc router
Product Details
| Condition | New | CNC or Not | CNC | |
| Place of Origin | Shandong, China | Brand Name | tianjiao | |
| Model Number | TJ12030 | Voltage | 380V | |
| Power(W) | 3KW | Dimension(L*W*H) | 3700*2200*2500 | |
| Weight | 2500KG | Certification | CE | |
| Warranty | 1 Year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
multi head 4 axis cnc drilling tools machine
1. machine picture
2.Application:
This machine is widely used in woodworking industry.. Wood table legs making, 3D relief carving
and cutting, statute making, etc.
4 axis cnc drilling, milling
1)high-speed 8 head equipment is mainly to solve low efficiency of tranditional wood processing industry, 8 heads can work at the same time, working efficiency is 8 times than single head.
2) mainly suitable industry: woodworking furniture carving ,wood crafts,wood carve patterns or designs, woodworking carving handicrafts.
3.parameters
Item | Specifications |
Working area | 1200mm length, 300mm diameter |
Rotary diameter | 300mm |
Table type | Aluminum profile table, table moving |
X,Y,Z Traveling Positioning Accuracy | ±0.03/150mm |
X,Y,Z Repositioning Accuracy | ±0.03mm |
spindle | 3kw water cooling spindle |
Spindle rotating speed | 0-24000rpm/min |
cutters | 10 cutters(6mm/12.7mm) |
Guider | 30 Taiwan PMI linear guider |
Transimission type | ballscrew imported bearings |
Control System | Original NC-Studio control system |
Motor | Taiwan Delta servo motor |
Driver | Delta servo driver |
Inverter | Delta inverter |
Software | JDpaint or Powermill |
Command | G code*.u00*.mmg * plt |
Surroundings for software | windows98/2000/xp |
Working voltage | AC380V 50Hz |
Packing size | 3.7*2.2*2.4m |
N.W | 2500kg |
G.W | 2600kg |
4.parts:
:
6. samples:
other 4 axis cnc carving machine model:
