TJ1325 balsa cnc router kit machine cutting MDF/wood
Jinan Tian Jiao Machinery Manufacture Co.,Ltd. is specialized in developing and manufacturing Mechanical CNC router (woodworking router, advertising router, stone engraving router), CNC Laser machine, Plasma cutting machine, cutting plotters, metal mould engraving machine and other cnc machines. We supply global market the high quality CNC equipments. We are leading company in this field and being confident in offerring the best service and best quality.
Pictures:
Features
This woodworking machine is economical type which with whole steel structure
1.The max speed is up to 25 meters/min, engraving speed is 20 meters/min
2.Adopting easy coperated DSP control system, it is convenient to operate.
3. Unique intelligent budget principle make the motors offerring the high speed, so
it could make the straight and smooth curves.
4.Double motors to drive Y axises
5.High strength steel tube jointing.
6.The table equipped with 6 divided vacuum zones.
Parameters
NO. Description |
Parameter |
|
1 |
Table size |
1480×3000mm |
2 |
X,Y working area |
1250×2440mm |
3 |
Z working area |
150mm |
4 |
Max. speed |
25m/min |
5. |
Working Speed |
20m/min |
6 |
Interface |
USB |
7 |
Command |
G code*.u00*.mmg* plt |
8 |
Surroundings for software |
windows98/2000/xp |
9 |
Power(spindle is not included) |
8.87KW |
10 |
Working voltage |
AC380V 50Hz |
11 |
Spindle power (domestic made) |
3KW water cooling spindle |
12 |
Spindle rotating speed |
0-24000rpm/min |
13 |
Drive Motor |
Stepper |
Specific Applications:
1. Advertising industry: cutting/engraving/drilling/photo engraving, cutting, drilling on wood, MDF, bamboo, plastic, PVC, acrylic, two colors board, metals,
stone etc.
2. Manufacturing industry: engrave, cut, drill, photo engraving on copper,
iron and aluminum, alloy, steel etc.
3. Furniture making: wood door cutting, wood door artwork engraving, wave
boards making, 3d photo engraving, small or large relief works, cylinder
materials engraving, 3d photo engraving etc.
4. Artwork industry: Figure engraving, character engraving and cutting,
name brand making, small gift cutting, souvenirs making, Carving various
decoration letters, figures on small windows, fences, wall, etc.
5. Model making: to cut materials into different shapes for models making.
6. Stamps making industry: Carving on many different materials like rubber, acrylic, cattle horn, plastic, wood and ink storage materials and so on.
Note: There are also some other industries application of cnc router machines,
pls confirm with us if you are not sure.
Optional parts
1. different type spindle
2. Bigger or smaller power spindles (6kw or 3kw)
3. High-grade cooling system (chiller, it has alarming system)
4. double-head or more heads
5. Cylinder rotary clamp (for cylinder materials working. Like cup, pen, bottles,
logs etc)
6. servo motors (China brand or Japan brand)
8. Auto tool change system (this system need other systems accordingly, like LNC control system, servo motors etc)
9. NCstudio control system
10. other customerized features
Note: Above are the main optionals, not all the machines can add above optionals, please contact us, we will give you suggestions, thanks.
Before sale
1.Patient introduce and professional suggest buying selection
2.Real time report production situation
3.Take pictures and make videoes with your done machine
4. Strict test and debugg machine quality before shipping
After sale
24 hours on line service and phone on
2 years gurantee term
During gurantee term, repair or change damaged parts for free
Exceed gurantee term, offer at cost price
