Mortar Pump
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Henan, China
Brand Name:
RISEN
Model Number:
RG50/40
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Henan, China
Brand Name
RISEN
Model Number
RG50/40
Specifications
Piston pump in grouting, conveying mortar;Output: 50L/min;
Max. Pressure: 40bar;
Power: 5.5kW (7.5hp);
The RISEN RG50/40 grouting machine is a piston mortar grout Pump with single cylinder and double acting.
Technical Data:
| Output Capacity : | 50L/min |
| Piston Diameter: | 90mm |
| Working Pressure: | 4Mpa (40bar) |
| Piston Stroke: | 85mm |
| Hopper Capacity: | 160L |
| Speed: | 95/min |
| Inlet Diameter: | 75mm |
| Outlet Diameter: | 50mm |
| Max. Particle size: | 5mm |
| Max. Aggregate Ratio (cement/sand): | 1:3 |
| Overall dimension (L×W×H) | 1610X1024X900mm |
| Net Weight: | 300kg |
| Power unit: | 5.5kW |
Application:
- Grouting cement mortar and sand mortar, combined with accessories such as compressor and spraying gun, in mine gallery, rail and road tunnel, hydropower construction, slope consolidation, underground engineering, subway and civil engineering etc.
- Applied in mortar or slurry spraying;
Feature:
- Single piston single acting
- Switch by ball valve
- Mechanical transmission, lower failure rate
- Integrate pump head and hopper; prevent eduction and deposition together with the paddle agitating
- Compact structure, convenient for maintaining
