Gunite Machine for Slop Stabilization
US$ 1,000 - 8,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New, New
Power Type:
Other, air driven
Place of Origin:
Henan, China
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai tianjin qingdao port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Gunite Equipment Export to AustraliaUS$ 2,000 - 9,000MOQ: 1 Set -
Best Seller Concrete Sprayed MachineUS$ 2,000 - 9,000MOQ: 1 Set
-
Machine Expert Serviceable Shotcrete PumpUS$ 1,000 - 8,000MOQ: 1 Set
-
Multi Function Gunite MachineUS$ 1,000 - 8,000MOQ: 1 Set
-
Dry Mix Guniting MachineUS$ 2,000 - 4,000MOQ: 1 Set
Power Type
Other, air driven
Place of Origin
Henan, China
Brand Name
RISEN
Model Number
PZ-5(air driven)
Power(W)
5.5kW (7.5 hp), 3-phase
Weight
720kg
Dimension(L*W*H)
1350*750*1020 mm
Specifications
Gunite Machine for Slop StabilizationOutput:5.5m3/h
Air consumption:7-8m3/min
Conv. Dis. 200m
Max. aggregate size15mm
Gunite Machine for Slop Stabilization
Technical Data:
PZ-5(air driven)
Output Capacity: |
5 cubic meter/hour |
Maximum Conveying Distance: |
200 m (660 ft) |
Desired Shotcrete Ingredient Ratio: |
Cement/sand and gravel < 0.35 |
Maximum Aggregate Size: |
15 mm (3/5”) |
Inner Diameter of Conveying Hose: |
51 mm (2”) |
Working Compressed Air Pressure: |
29 ~ 87 psi (0.2 ~ 0.6 MPa) |
Conveying Air Consumption: |
250 ~ 285 cfm (7 ~ 8cubic meter / min) |
Air Motor Power: |
5.5kW (7.5 hp) |
Dimensions: |
1350 x 750 x 1020 mm |
Net Weight: |
720 Kg |
Application:
- Shotcreting for tunnels, hydro-power engineering, mines, underground engineering, civil engineering and slope stabilization, etc.
- Artificial soil seeding for no soil surface, such as rock, sand, and for no fertility soil surface.
- Refractory spraying and repair for industrial kilns or kilns’ inner liner.
Common use:
1. Gunite Swimming Pool Construction.
2. Soil Retention and Tetaining Walls.
3. Rockscaping.
4. Refractory Spraying.
5. Mine Support.
6. Tunnel Linings.
7. Concrete Repair.
8. Artificial Rocks and Caves.
9. Low-volume Refractory Spraying.
Features:
- Non-adhesion going-through rotor with new material chamber, completely eliminate bonding and blocking during operation so as to reduce clearance and maintenance period.
- Thin follow conveying method with vortex flow, so the spraying flow is even, continuous and steady, to improve the shotcrete quality.
- Four-point clamping device make it easy to adjust the press between sealing plate and rotor disk so as to no air and dust leak and prolong consumption parts life.
- Particularly used for dry, damp mix and steel (polymer) fibre reinforced shotcrete.
- Three drive models: by Electric motor, air motor or diesel engine.
- For the most specific risks of this machine, safety and compliance with the essential requirements of the Directive has been based on elements of EN ISO 12100-1:2003, EN ISO 12100-2:2003/A1:1995, EN 60204-1:2006 and EN 1050:1997.
