30m Truck-mounted Concrete Pump
30m Truck-mounted Concrete Pump Technical Parameter
| ITEM | SYG5200THB 30 | |||
Vehicle Parameters |
Length | mm | 10095 | |
| Width | mm | 2500 | ||
| Height | mm | 3710 | ||
| Dead weight | kg | 20200 | ||
| Boom&Outrigger | Vertical reach | m | 30.1 | |
| Horizontal reach | m | 26.5 | ||
| Reach depth | m | 15.2 | ||
| Unfolding reach | m | 9.6 | ||
| 1st section | Length | mm | 7676 | |
| Articulation | 90° | |||
| 2nd section | Length | mm | 6090 | |
| Articulation | 180° | |||
| 3rd section | Length | mm | 6100 | |
| Articulation | 245° | |||
| 4th section | Length | mm | 6635 | |
| Articulation | 230° | |||
| Rotation | ±360° | |||
| Outrigger spread L-R---front | mm | 5850 | ||
| Outrigger spread L-R---rear | mm | 5440 | ||
| Pumping System | Output | m3/h | 120 | |
| Pressure | Mpa | 6 | ||
| Max. strokes | times/min | 30 | ||
| Delivery cylinder diameter | mm | 230 | ||
| Stroke length | mm | 1600 | ||
| Hydraulic system | Open | |||
| Hydraulic system oil pressure | Mpa | 32 | ||
| Oil tank capacity | L | 320 | ||
| Water tank capacity | L | 400 | ||
| Pipeline size | mm | 125 | ||
| End hose length | m | 3 | ||
| End hose diameter | mm | 125 | ||
| Chassis | Chassis model | Shaanxi SX1167DM521CR | ||
| Engine type | ISDe285 30 | |||
| Engine power | kW/rpm | 210/2500 | ||
| Emission standard | Euro Ⅲ | |||
| Capacity of fuel tank | L | 300 | ||
| Displacement | L | 6.7 | ||
| Max. speed | km/h | 85 | ||
| Brake distance | m/km/h | ≤ 10/30 | ||
SANY Truck-mounted Concrete Pump Core Technologies:
SANY Truck-mounted Concrete Pump Construction Case
Packing details&Shipping method
1.Most of our shipment will go by sea, to all main continents such as South America, Middle East, Africa, Oceania and Europe etc, either by container RoRo Bulk shipment.
2.For neighborhood countries of China, such as Russia , Mongolia ,Myanmar,Kazakhstan, Uzbekistan etc, we can by road or rail way.
3.For light spare parts in urgent demand, we can ship it by international courier service, such as DHL, TNT, UPS, Fedex.
1. WARRANTY
Twelve-month-period or 2000-hours warranty for any machine purchased from us
2. SPARE PARTS
Provide customers genuine spare parts with genuine quality, exact fitness and appropriate function
What are our advantages compared with manufacturer/factory?
1.Competitive Pric. 2.Quick Response 3.Fast delivery
Which payment terms we do?
Normally we can work on T/T term or L/C term, sometime DP term.
1. On T/T term, 30% down payment as deposit after order confirmation, and 70% balance shall be settled before shipment, or against the copy of B/L for old customers.
2. On L/C term, a 100% irrevocable L/C. A L/C draft is necessary before you open the formal L/C from the bank.
More detials needed,welcome to contact us!
