28 Disc 100-120HP Tractor Trailed Hydraulic Heavy-duty Offset Disc Harrow Model 1BZ-3.0

28 Disc 100-120HP Tractor Trailed Hydraulic Heavy-duty Offset Disc Harrow Model 1BZ-3.0 photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Farm Cultivator
Power Type:
Diesel
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao port China
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Farm Cultivator
Power Type Diesel
Certification CE,ISO9001:2000,3C
Use cultivating soil
Place of Origin Shandong, China
Brand Name Shallwin
Model Number 1BZ-1.8/2.0/2.2/2.5/3.0/3.4/4.0

Specifications

1.Working in 3m width 180-200mm width
2.Trail by 100-120HP tractor
3.Disc no.28,dia.660mm in Mn65 steel

28 Disc 100-120HP Tractor trailed Hydraulic Heavy-duty Offset Disc Harrow Model 1BZ-3.0





Description:

This series of 1BZ hydraulic trailed offset heavy-duty disc harrow is mainly applicable to clean the crop residue before tillage, break the hardened and impervious soil surface, crush and spread straw into the field, shatter soil after tillage, and level the land and preserve soil moisture. It can be used as tillage machine instead of plough on the cultivated land. With the efficient productivity, reasonable utilization of the power, great ability of cutting and shattering the soil , the soil surface is smooth and loosening after harrowing, it is well suitable for heavy clay soil, waste land and weedy field as well.



Having absorbed all advantages from such machines of foreigners and Chinese, it is designed according to the standarded assembled structure, the main frame is welded with rectangular tubes, on which assembled with hydraulic lifting transportation wheels, adjustable spring device and special used bearing assemblies.



Therefore this machine is strong and durable for operation and easy to be adjusted and maintained with the reasonable structure, small turning radius ,and is convenient for transportation , etc.





Main Specifications:

Model

unit

1BZ-3.0

Working width

m

3.0

Working depth

mm

180~200

Q’ty of disc



28

Disc diameter

mm

600/610/650/660

Over weight

kg

1450

Matched power

hp

100~120

Linkage

Trailed





28 Disc 100-120HP Tractor trailed Hydraulic Heavy-duty Offset Disc Harrow Model 1BZ-3.0



28 Disc 100-120HP Tractor trailed Hydraulic Heavy-duty Offset Disc Harrow Model 1BZ-3.0



28 Disc 100-120HP Tractor trailed Hydraulic Heavy-duty Offset Disc Harrow Model 1BZ-3.0
