1BZD Series Hydraulic Opposed Heavy-duty Disc Harrow for 80-180HP tractor
- 1000 Set / Sets per Month
- Qingdao port China
- T/T
Product Details
Condition: | New | Type: | Farm Cultivator | Power Type: | Diesel |
Certification: | CE,ISO9001:2000,3C | Warranty: | 2 years | Use: | cultivating soil |
Place of Origin: | Shandong, China | Brand Name: | Shallwin | Model Number: | 1BZD-2.8/3.3/3.8 |
Weight: | 2050-3400kg | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
1.CE certificate2.Working in 2.8~3.8m width,200mm depth
3.Trail by 80-180HP tractor
4.Disc no.24~32,dia.660mm in Mn65 steel
1BZD Series Hydraulic Opposed Heavy-duty Disc Harrow For 80-180HP Tractor
Description:
Adopting a frame type symmetrical structure, the disc harrow can eliminate the deflected tractive force produced by the implement on the tractor during the working process. The harrow is suitable for operations such as stubbing before plowing and soil crushing after plowing in the waste land, marsh and brush land and heavy soil.
Main Specifications:
Model | Unit | 1BZD-2.8 | 1BZD-3.3 | 1BZD-3.8 |
Overall dimension | mm | 5120*2700*1500 | 5260*3200*1500 | 5330*3680*1500 |
Working width | mm | 2800 | 3300 | 3800 |
Working depth | mm | 180~220 | ||
No.of blades |
| 24 | 28 | 32 |
Total Weight | Kg | 2050 | 2600 | 3100 |
Matched power | hp | 80~100 | 100~120 | 120~160 |
