Help CenterHigh Frequency Welded Tube Mill
Related Products
Commodity:
Technical Flow:
Uncoiling - Flattening-Shearing&butt welding-Strip Accumulating-Forming-High-frequency induction welding-Bead and burr removing-Zinc patching -Cooling-Sizing Inside Removing-UltrasonicTesting-Cutting-Checking &Collecting-Binding-Weighing-Marking-Accessing Warehouse
Technical parameters:
Circular Pipe Size |
114mm - 355mm |
Pipe Thickness |
6mm-16 mm |
Square Pipe Size |
90mm*90mm-280mm*280mm |
Pipe Thickness |
6mm-16 mm |
Material |
Carbon steel coil(GB Q195-Q345); Alloy steel coil; API 5L X42-X80 |
Pipe Length |
6 -12m |
Length Tolerance |
±3mm |
Line Direction |
right or left(from operator's side) |
Low carbon steel and low alloy steel: |
δb≤550Mpa ,δs≤235Mpa |
Production Speed |
Belong to confidential information and detail parameters will be known in the quotation list. |
Line Power | |
Electricity Input Power |
