Help CenterERW 508 Welded Steel Pipe Making Machinery
Related Products
Specifications
HG508 ERW steel pipe making machine is designed to produce pipe of OD 219MM-508MM and corresponding rectangle and square tubeCommodity: ERW steel pipe making machine For HG508
I. Summary
It is designed to produce welded pipes of Φ219mm-Φ508mm and6.0mm-16.0mm in wall thickness, as well as corresponding square (400mm×400mm) & rectangle (500mm×300mm) tubes. After we absorbed advanced pipe making technology home and abroad, our innovative production line and each single unit of the production line are not only economical but also practical. The complete production line adopts ZTF technology developed by our company when producing circle pipe. By means of ZTF technology, the customer shall reduce 60% expense on tooling and improve production effiency and create more economic benefit.
II. Basic Technical Information:
1. Production Specification
Circle Pipe OD: 219-508mm (8-20)
Thickness: 4.0-9.0mm
Max Square Tube: 400×400mm
Max Rectangle Tube 500×300mm
Max Length: 12 m
Length Tolerance: ±3mm
2. Raw Material: carbon steel strip b≤758Mpa, σs≤621 MPa
Steel Grade: X70, J55, carbon steel ST37-ST52
3. Line Specifications
Forming Technology: ZTF Roll forming technology for circle pipe,
Roll circle pipe into square and rectangle tube
Max Production Speed: 40 m/min
Direction: From left to right or decided by your side.
III. The technical flow of the production line
Coil Feeding→Uncoiling→Flattening→butt welding→Accumulating→Side Trimming→Forming→High-frequency induction welding→Removing outside & inner Bead →Polishing→Online UT → Seam Annealing→Cooling→Sizing→Cutting into length →Conveyer Table→Straightening→End Facing and beveling→Hydro Testing→Inspection→Packing→Warehouse
