pipe making machine

Specifications

Commodity:pipe making machine
1) OD:8mm-660mm
2) Thickness:0.3mm-20mm
Welcome to visit our factory

 Commodity:pipe making machine

Our pipe production line is designed to manufacture pipe or tube used in metallurgy, construction, transportation, machinery and vehicle industries.

We apply "ZTF" method during the pipe production procedure. It’s no need to change rolls in rough forming section when producing different size of pipes, and computer will control rolls moving, so that you won't worry about the accuracy. With this method, producers can save about 60% costs on rolls and reduce much working time.



Raw Material:

Carbon steel coil(GB Q195-Q345); Alloy steel coil; API 5L X42-X80



The technical flow of the production line:

Uncoiling→Shear & butt welding→Cage looping (Accumulating)→Forming → HFwelding→Removing outsied Bead →Cooling→Sizing→Cutting off→Conveying →Downloading → Packing →Warehousing



Specifications:

Model	Specification(mm)		Thickness (mm)	Working Speed(M/min.)
	Circular	Rectangular/Square
HG20	8-20	10*10-15*15	0.5-1.5	100
HG32	10-32	10*10-25*25	0.3-2.0	100
HG50	20-50	20*20-40*40	0.8-3.0	100
HG76	32-76	25*25-60*60	1.2-4.0	100
HG89	42-89	25*25-70*70	1.5-4.5	70
HG114	48-114	40*40-90*90	1.5-4.5	65
HG140	60-140	40*40-110*110	2-5	60
HG165	76-165	60*60-130*130	2-6	50
HG219	89-219	60*60-180*180	2-8	50
HG273	114-273	80*80-200*200	3-10	45
HG325	140-325	90*90-250*250	4-12.7	40
HG377 (355)	165-377 (355)	90*90-280*280	4-14	35
HG406	219-406	130*130-330*330	6-16	30
HG508	273-508		6-18	25
HG660	325-660		6-20	20
