Commodity: Pipe Making Machines for HG508
I. Brief introduce:
HG508mm welded pipe production line is designed to produce welded pipes of 273mm-508mm in OD and 6.0mm-18.0mm in wall thickness, as well as corresponding square and rectangle tube.
II. Basic Technical Information:
Specification | |
Round Pipe |
O.D:273~508mm |
Thickness:6.0~18.0mm | |
Square&Rectangular pipe |
215*215-400*400mm |
Thickness: 6.0~17.0mm | |
Length |
Length: 6 -12m Length Tolerance: ±3mm |
2.Raw Material: Low carbon steel and low alloy steel:
δb≤500Mpa δs≤235Mpa
3. Tube mill
Production Speed : Max 25m/min
III. The technical flow of the production line
IV. Makeup of tube mill line
1. Uncoiler
2. Shear & Butt Welder
3. Cage Loop (Accumulator)
4. Tube mill
5. Solid State H.F. welder
6. NC Flying Saw
7. Output Roll way
8. Rollers
Remark:
To protect confidential information, Here only show basic parameters. Detailed parameter will be
known in the quotation list or negotiate with customer.
