Dutch Weave Stainless Steel Wire Mesh Factory

Dutch Weave Stainless Steel Wire Mesh Factory thumbnail-1
Dutch Weave Stainless Steel Wire Mesh Factory thumbnail-2
Dutch Weave Stainless Steel Wire Mesh Factory thumbnail-3
Dutch Weave Stainless Steel Wire Mesh Factory thumbnail-4
Dutch Weave Stainless Steel Wire Mesh Factory photo-1
Dutch Weave Stainless Steel Wire Mesh Factory photo-2
Dutch Weave Stainless Steel Wire Mesh Factory photo-3
Dutch Weave Stainless Steel Wire Mesh Factory photo-4
US$ 6 - 14 MOQ: 100 Square Meters
Key Specifications
Get Latest Price
Place of Origin:
Hebei, China
Material:
Stainless Steel Wire
Type:
Weave Wire Mesh
Contact Supplier Request Quote Chat Now
Anping County Jiujiu Filter Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
TIANJINGANG
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Hebei, China
Material Stainless Steel Wire
Type Weave Wire Mesh
Application Filters
Weave Style Dutch Weave
Wire Diameter 0.5-8mm
Technique Welded Mesh
Brand Name MANCE

Dutch wire mesh has different Wire Diameter and mesh count. It can achieve the good filter density that square wire mesh can’t be achieved after reasonable collocation. So the Dutch wire mesh is fine wire mesh filter. The line wire is greater than weft wire in general.
Contrast type weave is called contrast because the weft wire is thicker than the line wire. (Dutch wire mesh reached the good filter accuracy that the general stainless steel mesh is impossible.)
Application: Used in precision pressure filters, fuel filters, vacuum filter, also apply to in aerospace, petroleum, chemical industry, chemical fiber, rubber tire manufacturing, metallurgy, medicine, food and other industries.





Specification of mesh count and aperture



Plain weave Dutch wire mesh

Model

mesh count(line wire X weft wire)

wire diameter

(line wire X weft wire)

aperture (um)

 KG/m2

32#

8 x 62

0.63mm x 0.45mm

300

5.42

40#

10 x 79

0.50mm x 0.355mm

250

3.16

48#

12 x 64

0.58mm x 0.40mm

280

2.9

55#

14 x 88

0.40mm x 0.30mm

180

2.54

76#

19 x 140

0.315mm x 0.20mm

140

1.88

80#

20 x 300

0.35mm x 0.20mm

-

3.6

95#

24 x 110

0.355mm x 0.25mm

120

2.45

100#

25 x 140

0.28mm x 0.20mm

100

1.95

120#

30 x 150

0.25mm x 0.18mm

80

1.68

140#

35 x 175

0.224mm x 0.16mm

71

1.52

160#

40 x 200

0.20mm x 0.14mm

60

1.40

180#

45 x 250

0.16mm x 0.112mm

56

1.09

200#

50 x 250

0.14mm x 0.11mm

53

1.04

220#

55.5 x 280

0.14mm x 0.10mm

50

0.92

240#

65 x 330

0.11mm x 0.08mm

36

0.71

280#(1)

70 x 350

0.11mm x 0.08mm

35

0.72

280#(2)

70 x 385

0.11mm x 0.07mm

32

0.75

300#

78 x 700

0.11mm x 0.08mm

30

1.39

315#(1)

80 x 400

0.10mm x 0.065mm

40

0.62

315#(2)

80 x 600

0.10mm x 0.06mm

-

0.74

315#(3)

80 x 800

0.15mm x 0.04mm

-

0.77

320#

81 x 780

0.10mm x 0.07mm

30

1.22

354#

90 x 550

0.12mm x 0.05

-

0.667

Width :1-1.6m











twill weave Dutch wire mesh

model

mesh count(line wire X weft wire)

wire diameter

(line wire X weft wire)

aperture (um)

KG/m2

360#

91 x 787

0.10mm x 0.07

25

1.24

400#

101 x 900

0.10mm x 0.063

20

1.22

472#

120 x 400

0.10mm x 0.075

-

0.862

500#

127 x 1100

0.07mm x 0.05

17

0.81

630#

160 x 1500

0.063mm x 0.04

15

0.62

650#(1)

165 x 400

0.071mm x 0.06

-

0.56

650#(2)

165 x 600

0.071mm x 0.05

-

0.575

650#(3)

165 x 800

0.071mm x 0.05

25

0.7

650#(4)

165 x 1100

0.071mm x 0.045

-

0.756

650#(5)

165 x 1400

0.071mm x 0.04

16

0.76

685#

174 x 1700

0.063mm x 0.032

13

0.61

787#(1)

200 x 600

0.071mm x 0.06

-

0.792

787#(2)

200 x 800

0.071mm x 0.06

-

0.972

787#(3)

200 x 1400

0.071mm x 0.04

12

0.8

795#

202 x 1760

0.05mm x 0.032

10

0.6

850#

216 x 1860

0.045mm x 0.030

9

0.518

1000#

254 x 2000

0.04mm x 0.028

8

0.5

1125#

285 x 2235

0.036mm x 0.025

7

0.439

1228#

312 x 2100

0.035mm x 0.025

-

0.423

1250#

318 x 2235

0.036mm x 0.025

-

0.449

1280#

325 x 2300

0.035mm x 0.025

5

0.45

1575#

400 x 3100

0.035mm x 0.019

3

0.369

width: 1-1.6m
