Help Center76mm Pipe Machine
Related Products
Specifications
Commodity: Pipe MachinePipe OD: 32mm-76mm Thickness: 1.5mm-4mm
Square tube: 25mm*25mm-60mm*60mm
Commodity |
Pipe Machine |
Round Pipe Size(mm) |
32mm -76mm |
Pipe Thickness (mm) |
1.5mm-4 mm |
Square Pipe Size(mm) |
25mm×25mm-60mm×60mm |
Pipe Thickness (mm) |
1.5mm-4 mm |
Material |
Carbon steel coil(GB Q195-Q345); Alloy steel coil; API 5L X42-X80 |
Pipe Length(m) |
6 -12m |
Length Tolerance(mm) |
±3mm |
Line Direction |
right or left(from operator's side) |
Production Speed(m/min) |
20-65m/min |
Low Carbon Steel And Low Alloy Steel: |
δb≤550Mpa ,δs≤235Mpa |
Technical Flow |
Scroll up→ Uncoil→ Flattening→ Cutting head, tail→ Strip Steel head-tail butt welding→ Looping storage→ Forming→ High-frequency induction welding→ Removing external burr→ Cooling→ Cutting→ Checking & Collecting→ Binding→ Accessing Warehouse. |
Tube Bottom Pass line/ Line Power/ Electricity Input Power etc. |
Belong to confidential information and detail parameters will be known in the quotation list. |
