Help CenterERW76 Pipe Mill
Related Products
Specifications
ERW76 HF welded pipe mill can produceround square rectangular profiled pipes with OD 20-76mm thickness 1.5-4.5mm
Commodity: ERW76 HF welded pipe mill
Technical Flow:
Uncoiling - Flattening-Shearing&butt welding-Strip Accumulating-Forming-High-frequency induction welding-Bead and burr removing-Cooling-Sizing Inside Removing-UltrasonicTesting-Cutting-Checking &Collecting-Binding-Weighing-Marking-Accessing Warehouse
Specifications
1.Product Specifications
I. Round pipe diameter range: 20-76mm
wall thickness :1.5mm-4.0mm
II. Square and rectangular tube : 25*25mm-60*60mm
wall thickness range 1.5-3.0mm
III .Tube and pipe length: 6--12m
2. Material Specifications:
Low carbon steel and low alloy steel: δb≤500Mpa
δs≤235Mpa
3 Line specification
production speed:0-70m/min
Line Direction: right to left(from operator' s side)
